INSTRUCTIONS FOR USE
Pro- 2 Ject Amp Box DS Mono
©
Pro Systems -Ject Audio · Pro- 2 Ject Amp Box DS Mono (from SN: 17A004755 201) · Revision 7.03.07
2
Dear music lover,
T - . hank you for purchasing an amplifier from Pro Ject Audio Systems
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply. The power cord is
used to disconnect the unit from the mains. Make sure that the power cord is easily accessible at all
times.
Never handle the device, the power cord/power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Tubes produce heat. Proper ventilation has to be guaranteed all the time. The unit must not be stacked.
Connectors
Make all connections whilst the amplifier is disconnected from the power supply.
The red speaker terminals carry the positive signal (+), the black speaker terminals the negative
signal (– ). Make sure the polarity of the connection is correct at each end of the cables.
Only connect one loudspeaker with an impedance not less than 4 ohms per channel.
Never use any other power supply than the one supplied with the unit.
Connection to the preamplifier
The RCA/cinch socket marked
In
In
In
InInput
put
put
putput
- is for connecting the cable from your pre amp or AV processor. Socket
marked
Bypass
Bypass
Bypass
BypassBypass
are input bypass.
Connection to the speakers
The output terminals accept loudspeaker cables terminated with 4mm ∅ Banana plugs, spades connectors
or naked wire.
!
!
!
© Pro Systems-Ject Audio - 2 · Pro Ject Amp Box DS Mono (from SN: 17A004755 201) · Revision 7.03.0
7
3
Mains power connection methods to switch the unit on and off and
Connect the low voltage plug from the power supply to the
2x48V=
2x48V=
2x48V=
2x48V=2x48V=
socket of the amplifier
be
be
be
bebefore
fore
fore
forefore
connecting the power supply to the mains. Amp Box DS2 Mono 2 can be switched on and off by using
different methods which are equal in priorities.
1. Using front pushbutton to switch on or into standby
The pushbutton on the front panel of the unit alternately turns the power on or returns it to standby mode. The
blue LED on the front panel shows that the unit is powered on.
Please note: If a trigger signal is present Amp Box DS2 Mono can’t be switched off by the
pushbutton.
2. Remote power on - triggers
Amp Box DS2 Mono can be switched on via other Box Design components when a 12V trigger voltage is
present at the 2.5mm socket marked
Tri
Tri
Tri
TriTrigger Inp
gger Inp
gger Inp
gger Inpgger Input
ut
ut
utut.
.
.
..
- Special power on cables (polarity ) in diverse
lengths are available as accessories. The remote power on signal can be relayed to further units via the -
Trigger Output
Trigger Output
Trigger Output
Trigger OutputTrigger Output
, socket. When the 12V trigger signal is switched off Amp Box DS2 Mono will also switch off.
Trigger cables may only be plugged into the sockets amplifier is disconnected from t when the he
power supply and from the mains. Failure to do so may result in damage of the unit.
Technical specifications Pro- 2 Ject Amp Box DS Mono
Power output 120 205 THD)W/ W at 8ohm/4ohm (<1%
Frequency response: - - 10Hz 50kHz (0dB, 3dB)
Channel separation: >40dB at 20kHz
Noise floor: >90dB
THD <0.1% at 90W
Gain 31dB
Pre in - 2 RCA (bypass input output)
Input sensitivity 550mV (100W, 4ohms)
Input impedance 10kohm
Speaker connectors: 4mm banana plugs
Trigger 12V switching voltage
Trigger in and out 2- pole coaxial 2,5mm jack
Outboard power supply: s mains supply +-48/2,5ADC, suitable for your countrie
Power consumption: 2,5A DC, <1W in standby
Dimension (W x D x H): 206 x 19 4 ; x 68 aluminium
240 x 194 x 69 wood
Weight 1 (without power supply): 440g aluminium,
1900g wood
+
