Sida 1/6
INSTRUCTIONS FOR USE
Pro-Ject Stereo Box 2 DS
© Pro-Ject Audio Systems · Pro-Ject Stereo Box DS2 · Revision 22.04.2021
2
Dear music lover,
Thank you for purchasing an integrated amplifier from P -Ject Audio Systems. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to connect/disconnect the unit from the mains. Make sure that the power supply
is easily accessible at all times. Never handle the device, the power supply while your hands are wet or
damp. Avoid letting liquids enter the device or the power supply. Never place any item containing
liquid, such as a flower vase on or near the device. Never spill any liquid on the device or the power
supply. Never place any naked flame sources, such as lighted candles on or near the device. The product
shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar
conditions.
Connectors
1. Make all connections except the connection the headphone and USB whilst the unit to is
disconnected from the mains.
2. Never connect or disconnect the power supply to or from the unit whilst the power supply is connected
to the mains. Never use any other power supply than the supplied one, with the exception of dedicated
Power Boxes which can replace original power supplies.
3. Take care to connect the left and right channels of RCA inputs correctly. The right channel is usually
marked red, the left channel black or white.
4 Speaker connections for the left speaker are located on the right hand side of rear view above,
.
.
.
. .
connections to right speaker are located on the left side Speaker connectors marked red represent . +
+
+
++
according indicators on speaker terminal.
Mains power connection and methods to switch the unit on and off
Connect the low voltage plug from the power supply to the socket of the unit
Power 3
Power 3
Power 3
Power 3Power 36V DC
6V DC
6V DC
6V DC6V DC bef
bef
bef
befbefore
ore
ore
ore ore
connecting the power supply to the mains. Stereo Box DS2 can be switched on and off by using 2 different
methods which are equal in priorities.
!
!
!
© Pro-Ject Audio Systems · Pro-Ject Stereo Box DS2 · Revision 22.04.2021
3
1. Using front pushbutton to switch on to standby or in
The pushbutton on the front panel of the unit alternately turns the power on or returns it to standby mode. The
blue LED on the front panel shows that the unit is powered on. If a trigger signal is present Stereo Box DS2
can’t be switched off by the pushbutton.
2. Remote power on - triggers
Stereo Box DS2 can be switched on via other Box Design components when a 12V trigger voltage is present
at the 2.5mm socket marked Special power- cables (polarity ) in diverse lengths are
Trigge
Trigge
Trigge
TriggeTrigger
r
r
r r Input.
Input.
Input.
Input.Input. on
available as accessories. The remote power-on signal can be relayed to further units via the
Trigger
Trigger
Trigger
Trigger Trigger Output
Output
Output
OutputOutput
socket. When the 12V trigger signal is switched off, Stereo Box DS2 will also switch off.
Trigger cables may only be plugged into the sockets when the amplifier is disconnected from the power
supply and from the mains. Failure to do so may result in damage of the unit.
Line o put ut
A power amplifier or active loudspeakers can be connected to the output sockets marked .
V
V
V
VVar
ar
ar
arar Output
Output
Output
OutputOutput
Record output, connecting a headphone amplifier
Fix Output
Fix Output
Fix Output
Fix OutputFix Output connects an analogue record device or a Pro-Ject Head Box headphone amplifier.
Connection to the speakers
The output terminals accept loudspeaker cables terminated with 4mm Banana plugs, spades connectors or
naked wire.
Phono input
Connect the tonearm signal lead to the P
P
P
PPhono
hono
hono
honohono
input of the amplifier. The MM/MC switch on the back panel
allows to adapt to connected cartridge type. The earthing wire may be connected to the screw terminal if you
encounter hum problems when using the turntable.
Line inputs
Line level sources such as CD player, radio or TV can be connected to the input sockets marked In
In
In
InIn In
In
In
InIn
2,
2,
2,
2,2,
3
3
3
3 3 or
or
or
or or
In4
In4
In4
In4In4.
Remote control
turns the unit on or back into standby
and adjust the sound volume
- and select the inputs
Blank button confirms pairing BT
Activate/deactivate mute
+
ON/OFF
VOL
+
VOL
1
CH
