INSTRUCTIONS FOR USE
Pro-Ject Pre Box RS
© Pro-Ject Audio Systems · Pro-Ject Pre Box RS (from S/N D16273) · Revision . 2014.10 27
2
Dear music lover,
thank you for purchasing a P -Ject Audio Systems preamplifier. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Tubes produce heat. Proper ventilation has to be guaranteed all the time. The unit must not be stacked.
Connectors
Make all connections whilst the preamplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
Wiring XLR sockets: 1 ground, 2 “hot” and 3 “cold”.
Never use any other power supply than the one supplied with the unit except of Pro-Ject Power Box.
Record output, connecting a headphone amplifier (RCA/phono sockets)
Out
Out
Out
OutOut connects an analogue record device ore a Pro-Ject Head Box headphone amplifier.
Out
Out
Out
OutOut provides a fixed output level.
Pre out (XLR sockets)
A power amplifier or active loudspeakers can be connected to the output sockets marked (balanced
P
P
P
PPre Ou
re Ou
re Ou
re Oure Out
t
t
tt
connection). For unbalanced connection use the supplied connection cable. Length of the cable is 41cm.
!
!
!
© Pro-Ject Audio Systems · Pro-Ject Pre Box RS (from S/N D16273) · Revision .2014.10 27
3
Inputs
The inputs (RCA/phono sockets) and (XLR sockets) provide higher gain. They are dedicated to
In1
In1
In1
In1In1 In
In
In
InIn 4
4
4
44
sources with low level output signal, e.g. phono preamplifier, tape deck, or FM tuner. The inputs and
In
In
In
In In 2
2
2
22 I
I
I
IIn
n
n
n n
3
3
3
33 In
In
In
In In 5
5
5
55 I
I
I
IIn
n
n
n n 6
6
6
66 (RCA/phono sockets) as well as and (XLR sockets) are suited to high level output sources like CD
player, D/A converter, or streamer.
Mains power connection
Connect the low voltage plug from the power supply to the Power
Power
Power
Power Power -20
-20
-20
-20-20V
V
V
V V
18
18
18
1818
socket before connecting the
power supply to the mains.
Remote control
turns the unit on or back into standby
and adjust the sound volume
and select the inputs
Front panel controls
To switch on from standby or to standby
The switch on the left hand side of the front panel turns the unit on or back into standby. The blue LED above
the stand-by switch shows that the unit is switched on.
After switching on, the tubes need a short time to reach the correct operating temperature. During
warm up the blue LED above the stand-by switch is blinking.
We recommend to set the volume control to 0, prior to switching on.
Input selector
After the unit is powered on, operating the switch next to the six LEDs selects the inputs. The selected input
will be shown by the corresponding LED.
Volume
Adjust the volume to the desired level, using the large knob on the front panel.
CH+
CH-
VOL+
VOL-
ON/OFF
ON/OFF
VOL
+
VOL
CH
+
CH
!
