Sida 1/2

PRODUCT INFORMATION

Technical data and price changes reserved.

Page 1/2

PRO-JECT AUDIO SYSTEMS

www.project-audio.com

• Suitable for MM and MC cartridges

• Precise RIAA equalisation

• Dual mono circuitry for optimized channel separation

• Selectable input inpedance on front

• Selectable input capacitance on front

• Low noise ICs

• Gold-plated RCA in & outputs

• Sandwich alu/metal casing protects from vibrations

and electromagnetic interference

• Colour options: silver and black, with optional wooden

sidepanels (walnut, rosenut, eucalyptus)

Input impedance: 10-47kohms

Capacitance: 100/120 and 320pF

Gain: 40/45/50/60/65 dB

Output voltage: 500mV @ 1kHz

(with 5mV input voltage @ 1kHz)

Noise oor: -80dBV

THD+N: < 0,02%

THD: 0,0008%

RIAA equalisation curve accuracy: within 0,5dB/20Hz -

20kHz

Input: 1 pair RCA

Output: 1 pair RCA

Power supply: 18V/500mA DC; 220 - 240V, 50Hz

Power consumption: 100 mA DC, < 1 watt standby

Dimensions W x H x D: 206 x 71 x 194 mm (alu)

240 x 72 x 194 mm (wood)

Weight: 1320g (alu), 1770g (wood) without power supply

PHONO BOX DS2

Phono preamplier

MSRP 349

€ (incl. VAT)

Incl. wood side panels MSRP 399

€ (incl. VAT)

colour options:

real wood side panels:

PRODUCT INFORMATION

Technical data and price changes reserved.

Page 2/2

PRO-JECT AUDIO SYSTEMS

www.project-audio.com

Phono preamplier for MM/MC

cartridges

Phono Box DS2 is a highly adjustable phono

preamplier suitable for all common MM and MC

cartridges. With the ability to switch easily between

input impedance and capacitance, as well as gain on

front it becomes one of the most user friendly phono

stages at this price point. It features one pair of

RCA inputs for your turntable and one pair of RCA

ouputs which will be conected to your pre-amplier or

integrated amplier. The casing is made of a durable

aluminium metal sandwich construction, which not

only will eectively protect it against electromagnetic

interferences and vibrations, but will also please the eye

with its simply and elegant esthaetics. Phono Box DS2

features a very linear circuit design to deliver the best

possible sound from a minimalistic PCB. With its high

value sonics and low cost price it becomes an audiophile

bargain!

black with rosewood side panels black with walnut wood side panels black with eucalypthus wood side panels

silver with rosewood side panels silver with walnut wood side panels silver with eucalypthus wood side panels

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	mottagare
Modell:	Phono Box DS2
Vikt:	1320 g
Bredd:	206 mm
Djup:	194 mm
Höjd:	71 mm
Uteffekt:	0.5 A
Total harmonisk distorsion (THD):	0.0008 %
Produktens färg:	Svart
Frekvensområde:	20 - 20000 hz
RCA-ljudingångar:	1
Strömförsörjning ingångsspänning:	220 - 240 V
Vinst:	65 dB
Synkroniserad ingångsimpedans:	47000 Ω
RCA-ljudutgångar:	1
Strömförsörjning ingångsfrekvens:	50 hz
Likström utspänning:	18 V
