INSTRUCTIONS FOR USE

Pro-Ject Phono Box DS3 B

Dear music lover,

thank you for purchasing a P -Ject Audio Systems phono amplifier. ro

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily

accessible at all times. Never handle the device, the power supply while your hands are wet or damp.

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such

as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never

place any naked flame sources, such as lighted candles on or near the device. The product shall not be used

in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Connectors

Make all connections whilst the phono amplifier is disconnected from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the

left channel black or white.

Do not connect the phono amplifiers output to a phono input (sometimes labelled

gram

gramgram, disc

disc

discdisc or RIAA

RIAA

RIAARIAA)

on the amplifier.

Never use any other power supply than the one supplied with the unit.

Connecting the record player

Connect the tonearm signal lead to the In

InIn -pin mini XLR, XLR or RCA) of the phono amplifier. If you connected (5

the lead to the RCA input, please also connect t grounding wire to the screw terminal of the Phono Box. he

Connection to the amplifier

Connect the (Balanced XLR or RCA) of the phono amplifier to a line input (such as

Output

OutputOutput

AUX

AUXAUX, ,

CDCD Tuner

Tuner

TunerTuner,

Tape

TapeTape Vid

Vid

VidVideo

eoeo or ) on your amplifier.

RCA and XLR outputs are separated and both play all the time. 2 amplifiers can be connected.

Mains power connection and methods to switch the unit on and off

Connect the low voltage plug from the power supply to the socket of the preamplifier

PPower 18V

ower 18V

ower 18Vower 18V before

before

before before

connecting the power supply to the mains.

1.1. Using front push

Using front push

Using front pushUsing front pushbutton to switch

button to switch

button to switch button to switch on or into stan

on or into stan

on or into stanon or into standby

dby

dbydby

The pushbutton on the front panel of the unit alternately turns the power on or returns it to standby mode. The

blue LED on the front panel shows that the unit is powered on. If a trigger signal is present, the unit can’t be

switched off by the pushbutton.

2.2. Remote powe

Remote powe

Remote poweRemote power on - trigg

r on - trigg

r on - triggr on - triggers

ers

ers ers

The unit can be switched on via other Box Design components when a 12V trigger voltage is present at the

2.5mm socket marked Special power- cables (polarity: ) in diverse lengths are

Trigge

TriggeTrigger

r r Input.

Input.

Input.Input. on

available as accessories. The remote power-on signal can be relayed to further units via the Trigger

Trigger

Trigger Trigger O

OOutpu

utpu

utpuutput

socket. When the 12V trigger signal is switched off, the unit will also switch off.

Trigger cables may only be plugged into the sockets when the unit is disconnected from the power

supply and from the mains. Failure to do so may result in damage of the unit.

Settings

Input

Selects balanced (5-pin mini ) or unbalanced ( ) input.

XXLR or XLR

LR or XLR

LR or XLRLR or XLR R

RRCA

CACA

2 turntables can be connected to the preamplifier and this button acts as input selector, settings for

each input are stored in memory.

Cartridge settings

The three push buttons on the right-hand side are used to set input impedance (Lo

LoLoad

adadin

ining

g g Ohm

Ohm

OhmOhms

ss), input capacitance

(Lo

LoLoad

adadin

ining

g g pF

pFpF) and input gain (Ga

GaGain

inin d

d dB

BB).

The button must be set to for using rotary controller Use the rotary controller to set

Load

LoadLoading

ing

ing ing O

OOhms

hms

hmshms Va

VaVariable

riable

riable riable .

. .

input impedance to desired value (10Ω 1000Ω). -ONLY

ONLY

ONLY ONLY IMPORTANT FOR LOW-OUTPUT MC

IMPORTANT FOR LOW-OUTPUT MC

IMPORTANT FOR LOW-OUTPUT MC IMPORTANT FOR LOW-OUTPUT MC CARTRIDGES!

CARTRIDGES!

CARTRIDGES! CARTRIDGES!

To find out which type your cartridge is please consult the literature accompanying your cartridge. The literature

for cartridges should also specify the correct input impedance and input capacitance, into which the cartridge

is designed to work. If in doubt, please consult your dealer.
