INSTRUCTIONS FOR USE
Pro-Ject Phono Box E BT5
© Pro-Ject Audio Systems · Pro-Ject Phono Box E BT5 · Revision 13.07.2021
2
Dear music lover,
thank you for purchasing this P -Ject Audio phono amplifier with Bluetooth® transmitter. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such
as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never
place any naked flame sources, such as lighted candles on or near the device. The product shall not be used
in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the phono amplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked
red, the left channel black or white.
Do not connect the phono amplifiers output to a phono input (sometimes labelled gram
gram
gram
gramgram, disc
disc
disc
discdisc
or RIA
RIA
RIA
RIARIAA
A
A
AA) on the amplifier.
Never use any other power supply than the one supplied with the unit.
Connecting the record player or a line level source
Connect the tonearm signal lead to the sockets Phono
Phono
Phono
PhonoPhono
In
In
In
InIn of the phono amplifier. Connect the earthing wire of
the tonearm signal lead to the screw terminal, if you encounter hum problems. The signal lead of a line level
source has to be connected to the socket Line
Line
Line
Line Line In
In
In
InIn (jack 3.5mm).
Input selector
Operating the push button Phono
Phono
Phono
PhonoPhono/Line
/Line
/Line
/Line /Line selects the inputs. “Phono” activates signal from Phono I
Phono I
Phono I
Phono IPhono In
n
n
nn RCA
sockets, “Line” activates line level input L
L
L
LLine
ine
ine
ineine In.
In.
In.
In. In.
Connection to the amplifier ( speaker/headphone) BT
The unit provides analogue and output connection. BT
Use the analogue Line
Line
Line
Line Line Out
Out
Out
OutOut output of the unit for connection to a line input (such as AUX
AUX
AUX
AUXAUX, CD
CD
CD
CDCD, Tuner
Tuner
Tuner
TunerTuner, Tap
Tap
Tap
TapTape
e
e
ee or
Video
Video
Video
VideoVideo) in your amplifier.
© Pro-Ject Audio Systems · Pro-Ject Phono Box E BT5 · Revision 13.07.2021
3
Line Out
Line Out
Line Out
Line OutLine Out acts as a direct bypass when input is selected. (Active also without power supply)
Line in
Line in
Line in
Line inLine in
Alternatively, the built-in Bluetooth transmitter allows to relay signal from inputs (Phono or Line) to any BT
receivers such as Pro-Ject MaiA S2 (S3) or Box E (S2, S2 HD) or directly to Bluetooth speakers or BT
headphones Transmitter connects to the receiver with strongest signal automatically. .
If you want to connect it to a Box E (S2, S2 HD) it is important to connect the Phono Box E BT5 to the power BT
supply first. Otherwise it is possible, that the boxes are not able to connect. The boxes connect automatically.
If the connection is successful, you will hear a sound. Now you are able to use it.
Output signal is always present on both outputs (analogue and Bluetooth ).
Mains power connection
Connect the low voltage plug from the power supply to the Power 18V socket of the phono amplifier before
connecting the power supply to the mains.
Technical specifications Pro-Ject Phono Box E BT5
Gain, MM: 34dB
SNR: 74dB
THD+N: 0,02% @ 1kHz
RIAA-equalisation curve accuracy: 20Hz - 20kHz / max. 0,5dB
BT transmitter: Version 5 (Class II), A2DP 2.1 support aptX aptX , , HD
BT range: 10 meters in direct visibility between source and receiver
Outboard power supply: 18V/500mA DC, suitable for your country's mains supply
Power consumption: 0mA DC 20
Dimensions W x H x D (D with sockets): 1 x 32 x 100 ) 20 (106 mm
Weight: 280g without power supply
Potential incorrect use and fault conditions
No signal on one or both channels:
No connection between signal source and phono amplifier or amplifier. This could be due to a faulty
plug, broken wire or solder joint or simply loose plug/socket connection.
Strong hum:
No earth connection from cartridge or arm, or arm cable to phono amplifier, or earth loop.
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the unit
be sent to the responsible distributor in your country.
