Sida 1/4

Unpack all items from accessory bag.

Remove dust cover carton from the box.

Lift the wrapped turntable out of the box.

Unpack the acrylic platter.

Put the drive belt on the pulley

& sub-platter.

Put the platter on the turntable.

Remove tonearm twist tie.

Put the counterweight in place.

Lower the tonearm lift and place the

tonearm between platter & armrest.

Balance the tonearm by turning the

counterweight until it stays level.

Turn the front scale of the counterweight

to zero without moving the weight itself.

Turn the counterweight counterclockwise

until the scale reads roughly 18.

Put the stylus protection cover back

on the cartridge.

counterweight

Connect it E

RCA cable

single adapter

& Allen key

drive belt

Antiskating

Weight

Unpack the power supply.

Carefully remove the protection covering.

Remove the stylus protection cover.

Put the loop of the Antiskating Weight

in the second groove on the tonearm

Unpack Dust Cover and put it on

the turntable.

Connect to your sound system and

have fun with music!

Small pulley- 33/45 RPM

Big pulley - 78 RPM (round belt)

0°

www.project-audio.com/en/products/x1-b

Technical Data

Speed

Principle

Speed variance

Wow & utter

Platter

Main bearing

Tonearm

33, 45, 78 (electronic speed change)

belt drive

33: 0.30% 45: 0.25%

33: 0.15% 45: 0.13%

20mm thick, 1.5 kg heavy acryl

stainless steel/brass

8,6” carbon/aluminium sandwich

Eective arm length

Overhang

Eective tonearm mass

Tracking force range

Power consumption

Dimensions

Weight

218,5 mm

18 mm

10,0g

0 - 30mN

5,0 watts max /< 0.3 watt standby

415 x 125 x 335 mm (WxHxD)

7 kg net / 9.5 kg gross weight

gloves

Tonearm is fragile!

X1 B

Setup Guide

Getting started:

• Make sure to have enough space to unpack your turntable.

• Always unpack and set up in a clean enviroment.

• Please Do throw away the packaging! If you need NOT

service or want to return your product, please send them in

the original packaging including all inserts. In case of any

damage in another packaging your dealer cannot guaran-

tee a full refund.

Complete Manual:

Plug in power supply and Connect it E*.

Yellow cable marks to the amplier.

* True Balanced Connect it E [Mini-XRL-Cable] available separately.

More information on the back of this setup paper.

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	Skivspelare
Modell:	X1
Inbyggd display:	Nej
Vikt:	7000 g
Bredd:	415 mm
Djup:	335 mm
Höjd:	125 mm
Modell:	Remdriven skivtallrik
Linjeutgångar (RCA):	2
Produktens färg:	Black, White
Vikt inkl. förpackning:	9500 g
Strömförbrukning (vanlig):	5 W
Material, hölje:	MDF
Frekvensområde:	20 - 20000 hz
På / av-knapp:	Ja
Strömförbrukning i vänteläge:	0.3 W
Nätaggregatstyp:	DC
Antal:	1
Signal/brusförhållande (SNR):	-68 dB
Turntable hastigheter:	33, 45, 78 RPM
Kanalseparering:	23 dB
Material, skivtallrik:	Akryl
Armlängd:	218.5 mm
Funktion:	Manuell
Penna typ:	mm
Platter vikt:	1500 g
Överhäng:	18 mm
Typ av pickup-arm:	Statiskt balanserad tonarm
