Installation manual

INSTALLATION MANUAL

It is the installer's responsibility to ensure that your waterproof LED TV is installed and sealed

correctly. Your warranty becomes void if problems occur due to faulty installation or poor sealing.

1. Decide on the correct position for your TV. Test the TV in that position to make sure the viewing

angle is appropriate for the viewing position. Each waterproof TV model has specic viewing

angels. Position the front bezel in order to view the picture clearly from all intended areas. Should

there be any doubt, make the area safe and power up the LED, positioning the screen until satised

that the picture does not darken or disappear from view.

2. Once you have your position check for any hazards that may stop you installing in this area, i.e.

cables or pipes. When mounting in stud walls, check for any supporting framework behind the

plasterboard.

3. Use the table below to work out the cut out size within the wall to t the TV. The recess in the

wall should be the cut to the size of the mounting plate dimensions.

4. Open up the cable cover by unscrewing all 8 screws, connect the power cable and the Arial (RF

cable) and also any other desired cables. Place the cable cover back, in line with the holes and

screw it back into place, making sure that it is secure and tight. Chase all cables into the wall at the

bottom of the TV to reduce chances of water reaching the TV.

5. When all the material is removed within the dimensions detailed to suit your size of the TV. Use

the screws provided to x the mounting case in place. Make sure the edges of the mounting case

are directly in line with the wall or tiles. Also make sure the mounting case is securely tted as this

supports your TV unit.

6. Now the TV is connected check that all the functions of the TV are working before tting. The

signal level feed to the TV must be at least 65db/1 mill volt or the picture may be noisy or pixelated

and dicult to tune. A distribution amplier may be required if you are in a weak signal area. If in

doubt, consult a qualied aerial technician.

Produktspecifikationer

Varumärke:	Proofvision
Kategori:	Tv
Modell:	PV19BF
Skärm diagonal:	19 "
Upplösning:	1366 x 768 pixlar
Wi-Fi:	Nej
Skärmform:	Platt
Ljusstyrka:	250 cd/m²
Antal HDMI-portar:	1
Inbyggda högtalare:	Ja
Kontrastförhållande (dynamisk):	10000:1
Internet-TV:	Nej
Miracast:	Nej
Fjärrkontroll ingår:	Ja
HD-typ:	HD
Betraktningsvinkel (horisontell):	170 °
Bredd (utan stativ):	482 mm
Höjd (utan stativ):	340 mm
Digitalt signalformatsystem:	DVB-T
3D kompatibilitet:	Nej
Nätverksansluten (Ethernet):	Nej
Smart-TV:	Nej
Native bildförhållande:	16:9
Bluetooth:	Nej
Svarstid (medel):	5 ms
Synfältsvinkel (vertikal):	170 °
Kvalitet på VGA (D-Sub) porten:	1
Antal S-Video-ingångar:	1
PC-In (D-Sub):	Ja
Antal talare:	2
Skärmgränssnitt (OSD):	Ja
Antal OSD språk:	8
