Sida 1/2
This manual applies to all
PRYMEBLU BT-500 series
adapters for radios with
SINGLE or DUAL PIN
accessory connectors.
3 4
2
Controls and Connection
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. To maintain compliance with FCC RF exposure
compliance requirements, please avoid direct contact to the transmitting antenna
during transmitting.
RF Exposure Warning!
Please keep product 20cm away from your
body or bystander during the radio operation.
The typical handheld radios were
certified under mobile usage condition
(i.e. keep 20cm away from the user body)
and use of such radio closer than 20cm may
exceed the US RF exposure limit
and shall be avoided.
Version 2.1.S February 2021
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: 714.257.0600
TOLL FREE: 800.666.2654
WWW.PRYME.COM
Wireless Adapter
Model No.: BT-500-Simple-Pin
Made in Taiwan
FCC ID: N2E-BTM01
The PRYMEBLU Adapter allows you to use a compatible wireless
headset or other audio accessory with your 2-way radio.
PRYMEBLU ADAPTER USER’S GUIDE
For Portable Radios with SIMPLE PIN accessory connector
PRYME® and PRYMEBLU® are trademarks owned by PRYME Radio Products,
Brea CA. All other product or service names are the property of their respective owners.
© 2021 PRYME Radio Products, Brea CA. All Rights Reserved
STEP ONE: Charging the PRYMEBLU Adapter
The PRYMEBLU Adapter has an internal Lithium Ion rechargeable battery pack which must be charged prior to operation, and must be
recharged regularly. A fully charged battery will provide approximately 10 hours (or more) of operation before needing to be recharged,
however, operating time can vary depending on usage and the condition of the battery pack. Recharge the battery regularly.
To charge the PRYMEBLU Adapter:
1. Ensure the PRYMEBLU Adapter is turned off, using the switch located on the back of the device.
2. Plug the supplied wall charger into a standard 120 volt AC outlet.
3. Plug the charger into the charge jack on the bottom of the PRYMEBLU Adapter. You will need to remove the protective rubber cover that
is inserted into the charge jack. (To prevent dust and moisture from damaging your adapter, always ensure this cover is in place when you
are not charging the adapter.)
4. Once the charging process has begun, the LED indicator on the top of the PRYMEBLU Adapter will show a constant blue light. Typical
charge time is approximately 5-6 hours. Actual charge time will vary depending on several factors including the battery’s charge state,
condition, and age.
6. Disconnect the charger from the adapter when charging is completed.
Charging Cautions:
- Use only the wall charger supplied by the manufacturer. Do not use any other charger.
- Do not use a wall charger that appears to be damaged. (Example: frayed wires, melted plastic, etc.)
Contact PRYME to get a new manufacturer-approved replacement charger.
- Do not tamper with or modify the PRYMEBLU Adapter or charger.
-Always turn the power switch to the off position when charging the PRYMEBLU Adapter.
Connecting the Adapter to RadioCharging the PRYMEBLU Adapter
STEP TWO: Connecting to a 2-way Radio
To connect your PRYMEBLU Adapter to a 2-way radio, follow these steps:
* Always turn off your 2-way radio before connecting the PRYMEBLU Adapter.
* Plug the PRYMEBLU adapter’s radio connector into the speaker-microphone / audio accessory jack of your 2-way radio.
* You can attach the PRYMEBLU Adapter to your 2-way radio or clothing using the Velcro fastener.
QUICK START
1. Connect the PRYMEBLU adapter to a compatible 2-way radio.
2. Pair the PRYMEBLU adapter with a compatible wireless audio accessory.
3. Test and use.
Multifunction Talk Switch
Used to place the PRYMEBLU
Adapter in pairing mode.
Once paired with an audio
accessory, this switch is used
to activate the Push-To-Talk
function of the 2-way radio
Status LED
The LED flashes messages that
let the user know the current
status of the PRYMEBLU Adapter
Velcro Fastener
or Belt Clip
Used to attach
the PRYMEBLU
adapter to the
2-way radio
or to the user’s
belt or lapel
Radio Connector
Plugs into the 2-way
radio’s Mic/Speaker jack.
Belt Clip Version
Velcro Fastener
Version
