1of2
ForStyleLUL5022C
PackageContents
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
Crossbar
Assembly
x1
CeilingCanopy
x1
FixtureChain
x1
QuickLink
x2
Pleasegotoforproductcleaningtips.Gototheselection.
(5)B10CandelabraBasebulbs60WMaximum,bulbnotincluded.
MinimumHangingHeightis29.5”,MaximumHangingHeightis77.5”.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.MissingParts?Contactyouroriginalplaceof
purchase.
www.quoizel.comCare+Maintenance
LightSource:
FixtureHangingHeight:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
A
B
C
D
STEP2-InstalltheCrossbarAssemblytoOutletBoxandAdjust
thelengthoftheNipple
A.AttachtheCrossbarAssembly(A)totheOutletBoxwiththeheadof
theGreenGroundScrewfacingyou.SecureitwithOutletBox
Screws(notincluded),tightenuntilsnug
B.Adjustthehexnutandlockwasherundersideofthecrossbartothe
middleofthenipple.
C.Removethecanopylockringfromthecanopychainloop.Placethe
CeilingCanopy(D)overthecanopychainloopagainsttheceilingto
determinethecorrectpositionofthenipple.Threadthecanopylock
ringontothecanopychainloop.AdjustthenippletoallowtheCeiling
Canopy(D)torestagainsttheceilingwhenheldinplacebythe
canopylockring.
D.RemovethecanopylockringandtheCeilingCanopy(D).Tighten
thelockwasherandthehexnutagainstthecrossbartosecurein
place.
.
OutletBoxScrew
(notincluded)
HexNutand
LockWasher
OutletBox
GreenGroundScrew
CanopyChainLoop
CanopyLockRing
Nipple
STEP3-InstalltheFixtureChainandCeilingCanopy
A.AdjusttheFixtureChain(B)toyourdesiredlengthbyremoving
linksifneeded.PutaclothovertheFixtureChain(B)toprotectthe
finish.
B.PullthesupplywiresthroughtheFixtureChain(B)alternatinglinks.
AfterthewiresarethroughtheFixtureChain(B),pulltheSupply
WiresandtheGroundWirethroughthecanopylockringandthe
CeilingCanopy(D)inorder.
C.AttachoneendoftheFixtureChain(B)tothefixtureloopwithone
QuickLink(C).LiftthefixtureandFixtureChain(B)upandattach
theotherendoftheFixtureChain(B)ontothecanopychainloop
withanotherQuickLink(C).Thefixturewillnowhangsafely.
D.FeedtheSupplyWiresandGroundWirethroughthecanopychain
loopandnippleintotheoutletbox.Cutthewiresleaving
approximately8”ofwireextendingfromtheOutletBox.
E.GotoStep5forwireconnectionsandfollowthedirections.Return
toStepFinthisstepwhencompletewithStep4.
F.RaisetheCeilingCanopy(D)andcanopylockringuptheFixture
Chain(B)andoverthecanopychainloop.Tightenthecanopylock
ringontothecanopychainloopuntiltight.
InstallationGuide#IS-LUL5022C
2018QuoizelInc.
ReleasedDate:2019-03-04
visituson-lineatwww.quoizel.com
A
D
Figure2
SocketAssembly
x1
F
CenterStem
x1
H
STEP1AssembleCageand
SocketAssemblies
-
a.UnfoldsupportarmsoftheFixture
LoopAssembly(E)toproper
locations.(RefertoSocket
Orientation)
b.Removethelockballfromthe
FixtureLoopAssembly(E).
c.PlaceCage(H)overthefixtureloop
assembly(E),Securewiththe
previouslyremovedlockball.
Hand-tightenuntilsnug.
FixtureLoopAssembly
(E)
D.Threadthe
,theCenterStem(F)andthe
SocketAssembly(H)togetheras
shown.Handtightenuntilsnug.
Figure1
FixtureLoop
Assembly
x1
E
G
Cage
x1
I
GlassAccentA
x25
(1pcreplacementpart)
J
GlassAccentB
x49
(1pcreplacementpart)
K
GlassAccentC
x1
E
F
G
H
lockball
