Type
Product Line
Type
Supported Models
DIMENSIONS
COLOR
PRODUCT DIMENSIONS
PACKING DIMENSIONS
(height x width x depth)
PACKAGE CONTENTS
MOUNTING INSTRUCTIONS
Consider the environment,
recycle where applicable.
In case of problems please contact your
reseller or sales@rackmount.it.
EMEA Ofce
Nonnenveld 27
4811 HN Breda
The Netherlands
T +31 76 200 37 40
E sales@rackmount.it
WWW.RACKMOUNT.IT
US Ofce
9201 Metric Blvd - Unit A
Austin - TX 78758
United States
T +1 512 521 03 33
E sales-us@rackmount.it
Qty Description
WG-RACK
RM-WG-T5
1.3/2U
WatchGuard Red
80 x 520 x 270 mm
3.14 x 20.47 x 10.63 in
57 x 482 x 217 mm
2.24 x 18.98 x 8.54 in
WATCHGUARD
FIREBOX T55
FIREBOX T35
1. Place the power supply on the rack and tie it down with 2 zip ties.
2. Remove the bolt from the side of your WatchGuard Firebox T35/55 with the Torx Key.
3. Place your WatchGuard on the rack, x the WatchGuard with the provided bolt and allen
key on the side of the appliance.
4. Tie the excess length of the power cable down with the 3rd zip tie.
5. Remove the label from its carrier and place it above the connectors on the front.
6. Connect the cables from your WatchGuard to the connectors.
7. Place your WG-Rack in your 19 inch rack.
8. Place the Rackmount.IT front plate BELOW the WG-Rack in your 19 inch rack. Together they
are 2U high.
Please sure proper ventilation according to the network appliance manufacturer guidelines.
1 WG-Rack + RJ45 couplers + front plate
3 Zip ties
1 Adhesive label
7 Cables - 0.5 meter
1 Allen Key + Torx Key
1 Bolt M3x6mm
Industrial version is supplied with shielded couplers and cablesRevision 3 - 26-10-2018
Produktspecifikationer
| Varumärke: | Rackmount.IT |
| Kategori: | ej kategoriserat |
| Modell: | RM-WG-T5 |
| Bredd: | 482 mm |
| Djup: | 217 mm |
| Höjd: | 110 mm |
| Förpackningens bredd: | 530 mm |
| Modell: | Monteringsskena |
| Snabbinstallationsguide: | Ja |
| Kompatibilitet: | WatchGuard Firebox T35, T55 |
| Rackkapacitet: | 1.3U/2U |
| Kopplingstyp: | RJ-45 |
| Kabellängd: | 0.5 m |
| Produktens färg: | Röd |
| Monteringssats: | Ja |
| Låddjup: | 270 mm |
| Antal per förpackning: | 1 styck |
| Kabel inkluderad: | LAN (RJ-45), USB |
| Antal kablar: | 7 |
| Harmonized System (HS)-kod: | 85389099 |
| Kopplingar ingår: | Ja |
| Antal kopplingar: | 6 |
