BigShot i/o
Owner’s Manual
True to the Music
Radial BigShot i/o users guide - Part #: R870 1125 10 / 06-2022
Subject to change without notice
8
6
9
7
10
3
BigShot i/o User Guide
Radial Engineering
RADIAL LIMITED THREE YEAR
TRANSFERABLE WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from de-
fects in material and workmanship and will remedy any such defects free of charge
according to the terms of this warranty. Radial will repair or replace (at its option)
any defective component(s) of this product (excluding nish and wear and tear on
components under normal use) for a period of three (3) years from the original date
of purchase. In the event that a particular product is no longer available, Radial
reserves the right to replace the product with a similar product of equal or greater
value. To make a request or claim under this limited warranty, the product must be
returned prepaid in the original shipping container (or equivalent) to Radial or to an
authorized Radial repair center and you must assume the risk of loss or damage.
A copy of the original invoice showing date of purchase and the dealer name must
accompany any request for work to be performed under this limited and transferable
warranty. This limited warranty shall not apply if the product has been damaged due
to abuse, misuse,misapplication, accident or as a result of service or modication
by any other than an authorized Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE
FACE HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY PERIOD
DESCRIBED ABOVE OF THREE YEARS. RADIAL SHALL NOT BE RESPONSIBLE
OR LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
OR LOSS ARISING FROM THE USE OF THIS PRODUCT. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH MAY VARY DEPENDING ON WHERE YOU LIVE AND WHERE
THE PRODUCT WAS PURCHASED.
BigShot i/o User Guide
Radial Engineering
1
2
3
4
INPUT-1 - ¼” jack for rst
instrument connection.
INPUT-2 - ¼” jack for second
instrument connection.
OUTPUT - ¼” jack connects
to amplier.
TUNER - ¼” jack connects
to tuner.
9VDC - power jack connec-
tion for power supply (for
LED’s only).
TUNER - switch determines
whether the TUNER output
is on all the time or only
when MUTE footswitch is
depressed.
8
9
7
5
TRIM - bypass switch for the TRIM
level control.
INPUT-2 LEVEL - control lets you
reduce the level of the instrument
connected to INPUT-2.
BRIGHT - three position switch
counteracts any effects from the
TRIM LEVEL control circuit and the
capacitive ltering effects from long
cables.
MUTE - footswitch with LED turns
the OUTPUT jack off for silent on-
stage tuning through the TUNER
output.
SELECT - footswitch with LED
indicator toggles between INPUT-1
and 2 to select the desired instru-
ment.
12
IMPORTANT NOTICE!
The Radial BigShot i/o is a passive switcher that is specically designed for use
with ampliers with proper electrical safety grounds that have been approved by
nationally recognized electrical authorities such as UL in the United States, CSA
in Canada and other similar bodies in countries around the world.
It is further understood that due to the unpredictable nature of connecting any
number of different ampliers and pedals together, using the BigShot i/o can
pose a potential for electric shock, and as such, the user is completely respon-
sible for any and all consequences as these are beyond our control.
This means that you are completely responsible to ensure the safe and proper
use of the BigShot i/o and to clearly understand that using the BigShot i/o
conrms you have taken full responsibility. If you are not 100% sure of your
actions, please consult a qualied technician for advice before using this device
or connecting any of your equipment to it.
CAUTION: PLEASE READ THE IMPORTANT NOTICE ON
THE BACK COVER BEFORE USING THE BIGSHOT i/o
FEATURES AND FUNCTIONS
6
45
11
10
11
Radial Engineering Ltd.
1845 Kingsway Ave,
Port Coquitlam BC V3C 1S9
Tel: 604-942-1001 • Fax: 604-942-1010
Email: info@radialeng.com
