CONGRATULATIONS on your purchase of the Twin-City AB/Y amp

switcher™. The Twin-City is an active switcher that enables you to connect

two amps and switch between them, or drive them both simultaneously

without degrading your natural guitar tone in any way. In our view, changing

the tone of a ’57 Strat is not an option!

The Twin-City buffer lowers the output impedance and susceptibility to in-

terference allowing you to drive long cables without tone loss or noise. Drag

Control™ is a recessed “set-and-forget” control that lets you compensate

for cable signal loss and introduce the perfect load to replicate the way

your guitar’s pickups naturally interact with your amp. Advanced Electronic

Impulse Switching (EIS) is 100% noiseless and free from popping noises

produced by mechanical switches.

To eliminate ground loops that cause hum and buzz, the Twin-City is

equipped with an isolation transformer on OUT-B. This output is further

augmented with a ground lift switch and 180º polarity reverse switch that

ensures both ampliﬁ ers play in phase while noise is reduced to an absolute

minimum, even when using older amps that are prone to noise.

Bright, easy to see LEDs deliver on-stage switching cues so you know ex-

actly what your amp status is at all times. The Twin-City is a powerful ABY

switcher that delivers all of the natural tone, punch and clarity without the

inducing noise of any kind.

THE TWIN-CITY

Requires an external power adapter that outputs 9 to 12 volts DC with a

2.1mm barrel jack wired center pin negative

. The Twin-City will

draw a max of 100mA. Possible damage may occur if another type of power

adapter is used. Consult your dealer for more information.

CONNECTIONS AND SETUP

Before you begin, turn your guitar ampliﬁ ers OFF. Connect the power supply

adaptor. An LED illuminates indicating the pedal is powered up and ready

for use.

Connect your guitar to the IN jack.

Connect OUT-A to your “A” ampliﬁ er.

Connect OUT-B to your “B” ampliﬁ er.

Always test your connections with your amps

set at a low volume level. Turn your amps

on. If no sound is heard check the guitar and

power connections.

Activate amp-A by depressing the TOGGLE

footswitch (LED A on). Adjust your amp to a

comfortable volume for playing. Depress the

TOGGLE footswitch again and set up amp-B.

Next, perform a polarity test to ensure the

loudspeakers in both amps are moving in

the same direction. With both amps active

and set to equal volume, ﬂ ip the 180° switch

to adjust the polarity of OUT-B. Listen to the

sound at both positions and choose the one

that sounds the fullest.

Finally, if you notice hum or buzz, try lifting the ground by sliding the LIFT switch.

Use the position that produces the least noise and you’re ready to rock.
