Sida 1/9
Manual-1
OPERATORS MANUAL
MM 8x MIXER
QUICK START
Here are a few basic “plug and play” steps to get you performing. If you are a first time DJ mixer user, please do
yourself a favor and at least read this section.
Begin by making sure your amplifier is off before making connections. The MM 8x has all unbalanced connectors,
except for the 1/4” balanced main outputs and XLR microphone inputs. Plug a source component, such as a CD player,
into one of the four LINE inputs on the rear. Connect the MAIN OUTPUTS to your amplifier. Set all front panel controls
to the middle of their travel and all pushbuttons to their out position. Slide the MASTER LEVEL down to 0. Set an
INPUT SELECT switch to your active source input. Plug in the MM 8x’s power supply and see the PWR indicator
illuminate. Turn on your source and amplifier. Slowly turn up the MASTER LEVEL and see the meters lighting and hear
music from your speakers.
In use, you can get tripped up at two places. If you have a phono signal into one of the four PH/LN inputs, be sure the
PH/LN switch is in the PHONO position (in); likewise, when using a tape deck or CD into these inputs, be sure the switch
is in the LINE (out) position. If you plug into the PROGRAM LOOP, the internal signal path is broken. Be sure that a
complete loop is made, to and from an outside device.
Couldn’t be easier, right?
Never connect anything except a Rane power supply to the thing that looks like a telephone jack on the rear or the
unit. This is an AC input and requires special attention if you do not have a power supply exactly like the one originally
packed with your unit. See the full explanation of the power supply requirements elsewhere in this manual.
Manual-2
FRONT PANEL DESCRIPTION
1. MAIN MIC ON switch: This switch puts the Main Mic signal into the mixer signal path. When the switch is pressed in, the
Main Mic is on and the adjacent red LED blinks.
2. Front panel MAIN MIC input: This 3-pin XLR input connects a balanced microphone. A parallel Main Mic input is on the
rear of the unit. Do not connect microphones to both front and rear Main Mic inputs.
3. MAIN MIC LEVEL control: This control adjusts the level of the Main Mic input.
4. MIC OVERLOAD indicator: This red LED monitors both microphone signals, before and after Mic EQ. It lights when the
signal exceed the Mic section’s output capability (3 dB below clipping). Occasional flickering is acceptable; however,
steady lighting requires a reduction in the Mic LEVEL control to prevent distortion.
5. AUX MIC ON switch: This switch puts the Aux Mic signal into the mixer signal path. The adjacent red LED blinks when
the switch is pressed in, indicating that the Aux Mic is on.
6. AUX MIC LEVEL control: This control adjusts the level of the Aux Mic input.
7. MIC EQ: These controls are used to contour the frequency response of the summed Main and Aux Microphone inputs.
8. Source Input Select switch: This switch selects either a Phono/Line or Line input for the channel. In the center position the
channel input is muted.
9. Source EQ: These controls are used to contour the frequency response of the selected source input.
10. Source Input fader: This fader controls the level of the input selected for the channel.
11. ACTIVE CROSSFADER: This fader controls the relative output level from the summed A and B mixes. When the fader
is at its far left, only the A mix is heard from the outputs. As the fader is moved toward the right, the amount of B mix is
increased and the amount of A mix is decreased. When the fader is centered, equal amounts of A and B mixes are routed to
the outputs. Fully right is all B mix at the outputs.
