Sida 1/6
Manual-1
OPERATORS MANUAL
SSA 6
MULTICHANNEL AMPLIFIER
QUICK START
You gots your good habits, and you gots your bad habits. A good habit is to read at least this much of the manual. A bad
habit is not to read any of this manual. Reading just this section can prevent grief worse than your worst nightmare. Grief
that's hard to get rid of—harder than a bad habit.
Be sure the amplifier is off before making any connections. Euroblock speaker connectors make connecting the ampli-
fier easy. They are just like little snap-on terminal blocks that take up to 12 gauge wire. Gold plated RCA connectors take
standard unbalanced sources. See Rane Note 110 for more information about other connectors. Keep your input cable
lengths as short as possible. Speaker loads should be no less than four ohms per output. If you are running multiple speak-
ers per Channel in series or parallel, check your final impedances.
If you are running six separate Channels (unbridged), be sure all the BRIDGED switches on the rear panel are de-
pressed. If you are running any Channels bridged, you are obviously a power user and we highly recommend you read
further into the manual regarding this issue.
With Input and Output connections completed, be sure all front panel LEVEL controls are all the way counterclock-
wise. Now flip the POWER switch and after hearing the relays click in after a second, notice that the READY lights come
on. Slowly turn up each Channel's LEVEL control to the desired gain and if all is well you should hear something pleasant.
If not, re-check connections, put on a better CD, and read more of the manual.
Manual-2
FRONT PANEL DESCRIPTION
1. POWER switch: Obediently turns the SSA 6 on and off every time you poke it with your finger (or other suitable object).
All six Channels have delayed turn-on/instant turn-off relays to eliminate any switching transients.
2. THERMAL overload indicator: This red LED lights up if the SSA 6 becomes too hot, indicating that power has been
removed from all six Channels. Be sure to check the fan filter and actual speaker impedances if this lights up.
3. POWER indicator: This magnificent blue LED lights whenever the SSA 6 POWER switch is turned on.
4. READY indicators: Each of these green LEDs light whenever the mute relay is passing the signal through to the speaker.
Normal operation is the on status.
5. LOAD LIMIT indicators: Each of these red LEDs lights whenever a Channel leaves the Safe Operating Area (SOA). This
means the amplifier turned down the Input level quickly and automatically, avoiding over-dissipation. Input signals 30 dB
over a safe limit will cause the READY indicator and mute relay to turn off until the amplifier has been turned off and the
problem corrected. Normal operation is the off status.
6. PEAK LIMIT indicators: These red LEDs light whenever a Channel’s Output cannot follow its Input. The amplifier has
turned down the Input level quickly and automatically, avoiding audible distortion. Normal operation is the off status.
7. Channel LEVEL controls: Each of these rotary controls determines the Input sensitivity of each respective Amplifier
Channel. At its full clockwise position, an Input signal of 0 dBu (.775 vrms) drives the Amplifier to full power. As the
controls are rotated counterclockwise, more Input signal level will be needed to achieve full power.
