User’s Manual

TABLE OF CONTENTS

GETTING STARTED……...……………..……................……………………..1

PACKAGE CONTENTS…………………………………………………………………1

QUICK INSTALLATION GUIDE………..……................……………………..2

TO INSTALL SOFTWARE AND DRIVER (FOR PC USER)………………………2

TO INSTALL SOFTWARE AND DRIVER (FOR MAC USER)………………………2

TO INSTALL HARDWARE………………………………………………………………3

ONE BUTTON SCAN FUNCTION………………………………………………………4

HOW TO SCAN FILM OR SLIDE………..……................……………………..5

CYBERVIEW X –

SF USER’S INTERFACE…................……………………..7

Ⅰ､MAIN WINDOW AREA【FIXED WINDOW】…………………………………8

Ⅱ､PREVIEW WINDOW AREA【FIXED WINDOW】……………………………16

Ⅲ､ACTIVE FRAME SETTING WINDOW AREA【FLOATING WINDOW】……18

TECHNICAL SUPPORT……………..……................………………………..19

GETTING STARTED

Check the package content before getting started.

For Quick Installation please refer to Quick Installation Guide.

Important! Please save the original box, receipt and packing materials for

possible return purposes.

Package Contents

‧ Film Scanner.

‧ Power Adapter.

[ Model : HPW-1512B (HIGH POWER) or LAD1512DBH (LINEARITY) ]

Warning! Using any other power adapter may severely damage the scanner

and will void the product warranty.

‧ USB 1.1 or USB 2.0 Cable. (subject to your purchased model)

‧ CyberView X - SF driver CD. ( SF = Single Frame capability. )

‧ TWAIN or Plug-In compliant application software CD.

‧ Printed User Manual.

REMARKS :

1. The models implented with Digital ICE

™ TECHNOLOGY please refer to Digital

ICE

3TM

user’s guide.

2. TWAIN or Plug-In compliant application software means the imaging software such

as Photoshop Elements, this is subject to change without notice.

Operating Ambient Temperature Range

50º to 104ºF (10º to 40ºC)

Note : Do not turn on the scanner unless it is within this range.

If the scanner has been stored or transported outside

of this range, allow it to return to within this range

before turning it on.

Operating Ambient Humidity Range

15% to 76% relative humidity (non-condensing)

Note : If the scanner is stored or to be transported in cold

temperature and then brought into a warm / humid

environment condensation may occur.

Produktspecifikationer

Varumärke:	Reflecta
Kategori:	Scanner
Modell:	iScan-3600
Vikt:	750 g
USB-version:	1.1
Bildsensortyp:	CCD
Kompatibla operativsystem:	Win 98/ME/2000/XP\nMac OS X 10.1.5 +
Standardgränssnitt:	USB 1.1
Maximal skanningsstorlek:	36 x 24 mm
Filmskanning:	Ja
Filmtyp:	negative, positive, 35mm
Färgskanning:	Ja
Produktstorlek (BxDxH):	166 x 268 x 66 mm
Skanningstyp:	Film-/diabildsscanner
USB-port:	Ja
Medföljande programvara:	ImageFolio, Mr. Photo, Page Manager
Mac-kompatibel:	Ja
Minimikrav, RAM:	256 MB
Minimikrav, processor:	Pentium III +
Ingång, färgdjup:	48 bit
Skannertid:	10 s
