Sida 1/2
Optional hardware
x(2)
x(2) x(4) x(2)
x(8)
A
B
C
D E
B
C
D
D
E
Attach each InfiniMount
Bracket to the Radio Motor
with the eight small screws.
Included in your
Radio Motor box
Insert the Thumb-Rollers into the InfiniMount
Brackets. Gently push to snap into place.
A
Complete the installation by plugging one end of the modular
cable into the left Thumb-Roller and the other end of the modular
cable into the left side of the Radio Motor. Then, repeat for the
right Thumb-Roller on the right side. Use the optional hardware
(if needed) to help mount the radio to the dash.
Thumb-Roller Quick Start Guide
What’s in the Box Installation
Hardware
Thumb-Rollers
Modern Sound For Your Classic
tech@retromanufacturing.com | help.retromanufacturing.com
Refer to the user manual included in your motor box or on our website for more comprehensive instructions.
Radio Presets
Redondo Mode
The following steps must be performed to set up the Radio Motor to function with the Redondo
Thumb-Roller controls. Press and hold the Left-Inside Thumb-Roller(1) for approximately 15
seconds to reboot the radio into SEL PANEL mode. While holding the Power Button the unit will
display the following sequence: RETROSOUND>RADIO>GOODBYE>TIME DISPLAY>SEL
PANEL, continue holding the thumb-roller until SEL PANEL is displayed. Once SEL PANEL is
displayed release the Left-Inside Thumb-Roller(1) and immediately press and release the Left-
Inside Thumb-Roller (1) to cycle through the choices until REDONDO appears. The Display
will Flash REDONDO 5 times and will turn off. Your Radio Motor is now configured to work with
your selected face.
Control Layout Basic Operation
Thumb-Roller Quick Start Guide
Modern Sound For Your Classic
tech@retromanufacturing.com | help.retromanufacturing.com
Power On/O
Press the Left-Inside Thumb-Roller(1) to power the unit on.
Press and hold the Left-Inside Thumb-Roller(1) to power the unit o.
Volume
Rotate the Left-Outside Thumb-Roller(2) up or down to change the volume.
Changing Source Modes
Rotate the Left-Inside Thumb-Roller(1) down to cycle through the source modes.
Changing Radio Bands
Rotate the Right-Inside Thumb-Roller(3) up to cycle through the radio bands.
Tune
Rotate the Right-Outside Thumb-Roller(4) to scroll through the stations.
Mute On/O
Press the Right-Outside Thumb-Roller(4) to mute and unmute.
Equalizer (EQ)
Press the Left-Outside Thumb-Roller(2) to enter the Tone Control sub-menu. Press and release the
Left-Outside Thumb-Roller(2) until you see the EQ setting you’d like to adjust. Rotate the Left-Outside
Thumb-Roller(2) up or down to adjust the setting. Press the Left-Outside Thumb-Roller(2) to move to
the next item, and repeat to adjust each option. Let the unit time out to set.
Setting the Clock
Press and hold the Right-Inside Thumb-Roller(3) to enter the System Settings sub-menu. Rotate
the Right-Outside Thumb-Roller(4) to cycle through the choices until you see CLK, then press
the Right-Outside Thumb-Roller(4) to select. Rotate the Right-Outside Thumb-Roller(4) up or
down to adjust the hours. Then press the Right-Outside Thumb-Roller(4) again to move on to
minutes. Rotate the Right-Outside Thumb-Roller(4) up or down to adjust the minutes. Let the unit
time out to setup .
Display Color*
Press and hold the Right-Inside Thumb-Roller(3) to enter the System Settings sub-menu. Rotate
the Right-Outside Thumb-Roller(4) to cycle through the choices until you see SCAN, then press
the Right-Outside Thumb-Roller(4) to cycle through the colors. Let the unit time out to set.
Beep On/O
Press and hold the Right-Inside Thumb-Roller(3) to enter the System Settings sub-menu. Rotate
the Right-Outside Thumb-Roller(4) to cycle through the choices until you see BEEP ON/OFF,
then press the Right-Outside Thumb-Roller(4) to choose between BEEP ON or BEEP OFF. Let
the unit time out to set.
Setting Radio Presets
To set a preset, tune to the station you want to set the preset to, and then press and hold the
desired Preset Button(5) for two seconds.
Recalling Radio Presets
To recall a preset, simply press the Preset Button(5) your station was set to previously.
1 Left-Inside Thumb-Roller
5 Preset Buttons
Right-Outside 4
Thumb-Roller
2 Left-Outside
Thumb-Roller
3 Right-Inside Thumb-Roller
*Some features are not available on all radios.
