ASSEMBLY INSTRUCTIONS FOR YOUR
RICO ESPINET MILES BOOM FLOOR LAMP
ASSEMBLY INSTRUCTIONS:
NOTE: Do not connect electricity until lamp is fully assembled.
1. Unpack all parts and place them on a level surface.
2. Align column (G) with base (I). Place threaded tube (H) through hole in base (I).
3. Hold column (G) and base (I) together and carefully turn the lamp onto its side. Slide washer (J) onto threaded tube (H).
Thread nut (K) onto tube (H) and tighten with wrench (O).
4. Carefully turn lamp into upright position.
5. Thread counterweight (F) onto the back of arm (E).
6. To adjust the position of the lamp, loosen the turn knobs and carefully move the arms into the desired location.
Re-tighten the turn knobs to secure the position of the lamp.
7. Lift shade (A) over the sockets. Slide split washer (C) between housing (D) and shade washer (B). Secure position of
shade (A) by turning shade washer (B) until it rests firmly against split washer (C).
8. Install two (2) 100W MAX. Type A bulbs into sockets.
9. Remove protective plastic (N) from polarized plug (M). Insert polarized plug (M) into wall outlet. Use switch (L) to
control/power to the lamp.
* To clean, use a soft cloth only. Do not use any chemical or abrasive cleaners. *
IMPORTANT SAFETY INSTRUCTIONS:
* This lamp comes with a polarized plug as a feature to reduce the risk of electrical shock. If the plug does not fit into
your outlet, contact a licensed electrician.
* NEVER alter the plug.
* Remove plug from wall outlet before replacing light bulb.
* Do not connect the electricity until lamp is fully assembled.
Z2097
(D)
(B)
(C)
TURN KNOB
TURN KNOB
(A)
(J)
(K)
(I)
(M)
(H)
(N)
(L)
(F)
(G)
(E)
(O)
Produktspecifikationer
| Varumärke: | Robert Abbey |
| Kategori: | Lampa |
| Modell: | Z2097 |
