Coconutz™
INSTALL INSTRUCTIONS
© 2021 MSE Audio. Rev. 02.19.2021
Ultra-Fidelity Outdoor Speakers
Contact: MSE Audio, 855.663.5600 / 913.663.5600 / [email protected]
Please read the following instructions carefully before installing
your Rockustics® Coconutz™ speaker. If you have any questions
regarding installation that are not answered in the following
directions, please contact your local sound contractor, or the
Rockustics®/MSE Audio® technical support team.
Basic Wiring
( Diagram A) Locate speaker wire on the top of the Coconutz.
If necessary, strip the wire ends and trim the wire to the
appropriate length. Use the supplied silicone wire nut to
connect the positive (red) leads of the speaker and input wires.
Repeat this step with the negative (black) leads.
NOTE: The provided wire nuts are meant for permanent installa-
tion use only. If you are temporarily wiring the speakers, do not
use these wire nuts. In the event you have used the wire nuts,
and need to re-wire your system, do not attempt to unscrew the
nuts. Instead, clip the wires below the nut, and follow the steps
in the section with a new pair of waterproof wire Basic Wiring
nuts (these are available at most hardware stores).
Mounting Instructions
NOTE: You will need one (1) mounting hook or eyelet rated for
30lbs (not supplied) per pair of Coconutz.
1) The Coconuts speakers are intended to be mounted using
the supplied hanging cable assembly (Diagram B).
2) It will be necessary to install a hook, loop, or eyelet (not
supplied) (Diagram C) that can adequately support the combined
weight of speakers being installed. Be sure to use hardware that
is rated for the combined total load of the speakers (30 lbs) and
ensure it is properly secured to the mounting surface.
3) (Diagram D) Clip one each of the cable ends to each of the
eyebolts in the Coconutz speaker.
5) Wire the speaker as described in the Basic Wiring section,
ensuring the weight of the speaker is supported by the hanging
cables, as opposed to the speaker wires.
Diagram A
Diagram BDiagram C
Diagram DDiagram E
Produktspecifikationer
| Varumärke: | Rockustics |
| Kategori: | högtalare |
| Modell: | Coconutz |
| Höjd: | 546.1 mm |
| Förpackningens bredd: | 622.3 mm |
| Diameter: | 438.1 mm |
| Färgnamn: | Sandsten |
| Rekommenderad användning: | Trädgård |
| Impedans: | 4 Ω |
| Lämplig för utomhusbruk: | Ja |
| Ljudutgångskanaler: | 2.0 kanaler |
| Högtalarplacering: | Golv |
| Bashögtalare: | Ja |
| Känslighet: | 91 dB |
| Ljudtrycksnivå (max): | 106.5 dB |
| Produktens färg: | Slipa |
| bruksanvisning: | Ja |
| Förpackningstyp: | Låda |
| Låddjup: | 635 mm |
| Vikt inkl. förpackning: | 21180 g |
| Antal per förpackning: | 1 styck |
| Uteffekt (RMS): | 70 W |
| Strömförbrukning (vanlig): | 64 W |
| Hållbarhetscertifiering: | CE, RoHS, Trade Agreements Act (TAA) |
| diskanthögtalare: | Ja |
| Material, hölje: | Elastomer |
| Frekvensområde: | 38 - 22000 hz |
| Anslutningsteknologi: | Kabel |
| Strömkälla av typen: | AC |
| Woofer diameter: | 203.2 mm |
| Woofer diameter (imperial): | 8 " |
| Bluetooth: | Nej |
| Högtalartyp: | 2-vägs |
| Högtalarlåda: | Stängd |
| Antal woofer-drivenheter: | 1 |
| Högsta musikuteffekt (PMPO): | 140 W |
| Disktanthögtalare diameter: | 0.75 " |
| Antal tweeter förare: | 1 |
