Original Rock Speakers

INSTALL INSTRUCTIONS

Ultra-Fidelity Outdoor Speakers

Contact: MSE Audio, 855.663.5600 / 913.663.5600 / sales@mseaudio.com

Please read the following instructions carefully before

installing your Rockustics

Rock speaker. If you have any

questions regarding installation that are not answered in

the following directions, please contact your local sound

contractor, or the Rockustics

/MSE Audio

technical

support team.

Basic Wiring

(Diagram A) Locate speaker wire on the underside of the

rock. If necessary, strip the wire ends and trim the wire to the

appropriate length. Use the supplied silicone wire nut

to connect the positive (red) leads of the speaker and

input wires. Repeat this step with the negative (black) leads.

Rockustics recommends using 14ga or heavier Direct

Burial cable for the connection between the amplier and

speakers.

NOTE: The provided wire nuts are meant for permanent

installation use only. If you are temporarily wiring the

speakers, do not use these wire nuts. In the event

you have used wire nuts, and need to re-wire your

system, do not attempt to unscrew the nuts. In-

stead, clip the wires below the nut, and follow the

steps in the section with a new pair ofBasic Wiring

waterproof wire nuts (available at most hardware stores).

Optimizing Speaker Placement for

Best Sound

All Rockustics speakers can generate a high SPL (sound

pressure level). Be ready to rock, but be considerate of

your neighbors! Maximum acoustic performance should

be an important factor in determining speaker placement.

Here is how to achieve it:

1) Establish where the most likely or average listening

position will be.

2) The speakers should be placed at or close to the

same distance from that point.

3) The actual distance between the listening position

and the location of the speakers is not critical. How

ever, keep in mind that as the distance between

listening area and speaker is increased, there will be

a noticeable decrease in perceived volume.

4) Be sure to conrm amp power matches the power

rating on the speaker. Over-driving the speaker can

lead to permanent damage that is not covered under

warranty.

Optimizing Aesthetics with

Speaker Placement

All Rockustics products are designed with a boost in high

frequency response to accommodate for placement near

plants and other landscaping features. Feel free to position

the product within your landscaping, camouaged near

bushes or shrubs. Rockustics products strive to blend into

Diagram A

Produktspecifikationer

Varumärke:	Rockustics
Kategori:	högtalare
Modell:	StoneHenge II-S
Höjd:	552.45 mm
Förpackningens bredd:	615.95 mm
Diameter:	438.15 mm
Färgnamn:	Sandsten
Rekommenderad användning:	Trädgård
Impedans:	4 Ω
Lämplig för utomhusbruk:	Ja
Ljudutgångskanaler:	- kanaler
Högtalarplacering:	Golv
Bashögtalare:	Ja
Känslighet:	87 dB
Produktens färg:	Slipa
bruksanvisning:	Ja
Förpackningstyp:	Låda
Låddjup:	438.15 mm
Vikt inkl. förpackning:	20230 g
Antal per förpackning:	1 styck
Uteffekt (RMS):	150 W
Strömförbrukning (vanlig):	120 W
Hållbarhetscertifiering:	CE, Trade Agreements Act (TAA)
diskanthögtalare:	Ja
AC-inspänning:	100 V
Material, hölje:	Elastomer
Frekvensområde:	70 - 19000 hz
Anslutningsteknologi:	Kabel
Strömkälla av typen:	AC
Woofer diameter:	203.2 mm
Woofer diameter (imperial):	8 "
Bluetooth:	Nej
Högtalartyp:	2-vägs
Högtalarlåda:	Stängd
Antal woofer-drivenheter:	1
Högsta musikuteffekt (PMPO):	300 W
Disktanthögtalare diameter:	19.05 mm
Antal tweeter förare:	1
