Rocstor Y10A314-B1 Bruksanvisning
Rocstor
datatillbehör
Y10A314-B1
Läs gratis den bruksanvisning för Rocstor Y10A314-B1 (2 sidor) i kategorin datatillbehör. Guiden har ansetts hjälpsam av 14 personer och har ett genomsnittsbetyg på 3.6 stjärnor baserat på 7.5 recensioner. Har du en fråga om Rocstor Y10A314-B1 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/2
Features
DisplayPort Male
Rocstor introduces the DisplayPort1.4 to Triple HDMI Adapter, designed to expand a
DisplayPort-based host to three HDMI ports with ultra-high denition capability.
Supporting DP1.4 alt mode, this product enables the output of dual maximum
4K/60Hz videos or triple videos (maximum 4K/60Hz + 2x4K/30Hz) simultaneously
under MST mode.
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in it:
• Main Unit x1
• Micro USB to USB-A Cable x1
• User Manual
HDMI Female X3
• Compliant with DP1.4 alt mode up to
8.1Gbps (HBR3), downward compatible
with 5.4 Gbps (HBR2), 2.7 Gbps (HBR)
and 1.62 Gbps (RBR)
• Supports HDMI max 4K/60Hz per port,
dual max 4K/60Hz under MST (output
dierent pictures simultaneously) or
output triple displays (max
4K/60Hz+2x4K/30Hz) under MST
• Supports 8/10/12 bit color depth output
• Supports output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0
• Supports HDCP2.2&1.4
• Supports HDR which ensures every
moment of a video is displayed at its
ideal values for depth, detail, brightness,
contrast and wider color gamuts on a
scene by scene or even a frame by frame basis
Note: To achieve the above resolution, the
host should support DP1.4, when
working on DP1.2 host, the correspond-
ing resolution will be decreased due to
bandwidth limitation. The above
resolution combination is for theoretical
reference, the actual output resolution
depends on the connected host and
displays
Upstream:
Downstream:
• Supports DP1.4 Alt mode
Micro USB X1 (For Power)
• Supports Gigabit
Ethernet,10M/100M/1000M
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no
light when no Internet connected,
orange light turns on when network
connection is established, yellow light
ashes when transmitting data
Package Contents
Specication
Input
Output
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
Introduction
Environmental
Input / Output Connector
Certications
Regulatory Approvals
User Manual
Accessory Adapter
Warranty
Limited Warranty
HDMI
HDR
Resolution
Size (L-W-H)
Mechanical
Weight (Net)
Standby Power Consumption
HDCP Version
Power Requirement
Power Source
HDMI Female x3
DisplayPort Male x1
3 Years
0°C to 45°C (32°F to 113°F)
5% to 90 % RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 85% RH (no condensation)
FCC, CE
English Version
Support
Max dual 4K/60Hz
3.9x1.4x0.45in (100.82x36x11.5mm)
1.98lbs (56.2g)
≤0.3W
HDCP2.2&1.4
Micro USB
®
DisplayPort 1.4 to Triple HDMI
Adapter with MST
User Manual
Y10A314-B1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
