Sida 1/2
Features
USB Type-C Male (Connect to host computer)
• Supports DP1.4 Alt mode, with bandwidth max 2 lanes 16.2Gbps (8.1Gbps per lane),
downward compatible with DP1.2 Alt mode
Note: To get max bandwidth, the host should support standard DP1.4 Alt mode
with DSC3:1 and HBR3
HDMI
• Supports HDMI max 4K/60Hz， 4：4：4，
8bit with 18Gbps Bandwidth
• Supports 6/8/10/12 bit color depth
output
• Supports output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2
• Supports HDCP 2.2&HDCP1.4
• Supports HDR
Note: When connecting a DP1.4 Alt
mode supported host, the max
resolution of HDMI is 4k/60Hz; When
connecting a DP1.2 Alt mode supported
host, the max resolution of HDMI is
4k/30Hz due to bandwidth limitation
Introduction
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the shipping carton:
• Main Unit x1
• User Manual
Rocstor presents a Type-C 5-in-1 hub featuring HDMI, 3 USB-A ports, and a
Type-C female port, oering an optimal solution for expanding the port options
of Type-C/Thunderbolt 3 hosts such as PCs, laptops, and mobile phones,
particularly benecial for devices with only one Type-C port. Equipped with the
latest DP1.4 Alt mode supported IC, this hub enables HDMI video output at a
maximum resolution of 4k/60Hz while concurrently transferring USB 3.1 data at
up to 5Gbps. The 3 USB-A ports facilitate simultaneous connection of 3 USB
devices. Furthermore, the Type-C female port supports PD 3.0 with a maximum
power delivery of 100W for PD Charging. Compatible with all DP Alt mode
supported Type-C hosts, this hub ensures versatile compatibility and
functionality.
Type-C Female (for PD Charging)
• Supports PD Charging 100W (20V/5A)
• Supports Fast Role Swap of PD 3.0, the
connected device will not get
disconnected while plugging in and
out PD Adapter
• 8W is dedicated to the functioning of
this product, the rest power (max 92W)
will be passed to charge for the host
Upstream:
Downstream:
Specication
Input / Output Connector
Input
Output
HDMI Female p1-x1
USB-A Female x3
Type-C Female x1（PD Charging)
Type-C Male x1
Warranty
Limited Warranty 2 Years
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
0°C to + 45°C
10% to 90 % RH (no condensation)
-10°C to + 70°C
10% to 90 % RH (no condensation)
Accessories Adapter
User Manual
Physical
Weight
Size
0.11lbs (53.3g)
4.5x1.3x0.37in (105.7x34x9.46mm)
Power Supply
USB-C PD Charging Port 100W(20V/5A)
English Version
FCC, CE
Regulatory Approvals
Certications
Electronic Parameter
Input Voltage
Power Consumption
5V
Max 2W
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Type-C to HDMI/USB-Ax3/Type-C
PD Charging with DP1.4 Alt mode
User Manual
Y10A308-B1
USB-A 3.0 X3
• 1 USB-A port （next to HDMI port)
supports max downstream charging, 3
USB-A share max 8W (5V/1.6A)
downstream charging.
• Max 5Gbps bandwidth
Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: +1 (818) 727-7000
(National and international)
Fax: +1 (818) 875-0002
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Connection Diagram
Safety Information:
Email: support@rocstor.com
WARNING:
Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the device adapter becomes very warm during use.
Please note that:
Continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the device and use care when handling it. Avoid instances where your skin is in extended contact
with the device when plugged into the host computer. It is not recommended to sleep with the
device when plugged into a host computer. Avoid placing the device under a pillow, blanket, or your
body when connected to a host computer. If you have a medical condition that aects your ability to
detect heat against the body, extra care should be used. Never use the device in locations with water,
such as a sink, bathtub, or shower stall. Never connect or disconnect the device with wet hands.
Limitation of Liability
In no event shall the liability of Rocstor, Inc. and Rocstor (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (2) two-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Type-C
PD Adapter
TIMELINE WORLDWIDE PROJECTIONS
M
ANUFACTURING
O
PTIONS
NORTH AMERICA UNITED KINGDOM GERMANY CHINACHINA SOUTH KOREA JAPAN
TIMELINE MANUFACTURING
CUSTOMER INTERATION
GROWTH FORCAST WORLDWIDE DEVELOPMENT
This statistic shows the year-over-year
growthof manufacturing and sales
Worldwide. Projections are from
2010 to 2060.
We delivered $22.0 billion in revenue
and $10.3billion in operating
income this past scal year.
We delivered $26.0 billion in revenue
and $12.5billion in operating
income this past scal year.
We delivered $30.0 billion in revenue
and $16.5billion in operating
income this past scal year.
We delivered $36.0 billion in revenue
and $20.3 billion in operating
income this past scal year.
We delivered $42 billion in revenue
and $26.2 billion in operating
income this past scal year.
We delivered $48 billion in revenue
and $28.8 billion in operating
income this past scal year.
EXCELLENCE IN SERVICE GLOBAL EXCHANGE PARTNERSHIP DIRECT SALES GLOBAL CONNECTIONSEXPEDITED EXECUTION
CUSTOMER SERVICE
Our timeline is a display of a list
of events in chronological order.
It is typically a graphic design
showinga long bar labelled with
dates alongside itself.
Our manufacturing is the production
of merchandise for use or sale
using labourand machines, tools,
chemical and biological processing,
or formulation.
Customer Interaction Management
(CIM) Customer interaction
management is the process followed
by companies to interact with its
customers.
Worldwide teamed up to conduct
a survey of more than 500
respondents focused on creating
eective leaders and preparing
the next generation.
The process of improving some
measure of an enterprise's success.
Business growth can be achieved
either by boosting the top line
or revenue of the business.
HDMI Display
4K @ 60Hz
Thunderbolt 3 /
Type-C Host PC
!
USB-A (Ports 1 and 2),
Devices Max 5Gbps 1.6A
USB-A (Port 3)
Max Downstream
Charging
