Functions Added in Ver.1.80

Undo/Redo Function Added

This function lets you revert a phrase to how it was just before it was

edited.

* The messages “Can’t UNDO” or “Can’t REDO” are shown when undo/

redo can’t be performed.

Undoing the previous operation

(UNDO)

Press the [EXIT] and MEASURE [<] buttons at the same time.

“UNDO” is shown in the display, and the sequencer returns to the

previous state.

For a step recording, this undoes the step that you just inputted or

erased.

For a real-time recording, this undoes the recorded step and motion

state.

* When you switch between tracks or clips, the undo content is erased.

* You can’t undo or redo while recording in real time.

* You can undo up to 10 times.

Reverting an Undo Operation

(REDO)

Press the [EXIT] and MEASURE [>] buttons at the same time.

“REDO” is shown in the display, and the data reverts to how it was

before you did the undo operation.

Added Function for Continuously Assigning Sliced Samples

A sampling function has been added for continuously assigning sliced

samples.

In step 7 (loading into a track) of “Sampling to a tone or drum track”

(P.16), you can now press the [ENTER] button while holding down

the [NOTE] button to continuously assign sliced samples each time you

press the button.

Exciter, Phonograph and JD Multi Added to MFX

An Exciter eect has been added to the Filter category, a Phonograph

eect has been added to the Lo- category, and a JD Multi eect has

been added to the Combination category.

Exciter

This adds dynamics to the sound, by dynamically bringing up the high

end using a split-band compressor.

L out

Low

Mid

High

L in

Compressor

Channel

Divider

R out

Low

Mid

High

R in

Compressor

Channel

Divider

Parameter Value Explanation

Band2 Th -80.0–0.0 (dB)

Raises the midrange frequency levels when

they fall below the specied amount.

Parameter Value Explanation

Band2 Gain 0–+24 (dB)

Sets how much to raise the levels when the

midrange volume is low.

Band3 Th -80.0–0.0 (dB)

Raises the high-end frequency levels when

they fall below the specied amount.

Band3 Gain 0–+24 (dB)

Sets how much to raise the levels when the

high-end frequency volume is low.

Split1 F 2000–5000 (Hz)

Frequency at which the low and midrange

frequencies are split

Split2 F 3000–10000 (Hz)

Frequency at which the midrange and high-

end frequencies are split

Level 0–127 Output Level

Phonograph

Recreates the sound of an analog record being played on a record

player. This lets you simulate the unique noises produced when a

record is played, as well as the variations that occur when the record

spins.

Balance W

Balance D

R outR out

L outL out

BalanceW

L inL in

PhonographPhonographPhonographPhonograph

R inR in

PhonographPhonographPhonographPhonograph

Parameter Value Explanation

Signal Dist 0–127 Sets the amount of distortion.

Freq Range 0–127

Sets the frequency characteristics of the playback system.

Smaller values create the feeling of an older system with

narrow frequency bands.

Disc Type LP, EP, SP

Sets the turntable rotation speed.

This has an eect on the scratch noise cycle.

Scratch NZ 0–127 Sets the volume of noise created by scratches in the record.

Dust NZ 0–127 Sets the volume of noise created by dust on the record.

Hiss NZ 0–127 Sets the volume of continuous hiss noise.

Total NZ 0–127 Sets the volume of noise overall.

Wow 0–127 Sets the amount of variation in record spin (long cycle).

Flutter 0–127 Sets the amount of variation in record spin (short cycle).

Random 0–127 Sets the amount of non-cyclical variation in record spin.

Total W/F 0–127 Sets the volume of variation in record spin overall.

Balance

D100: 0W

-D0: 100W

Sets the volume balance between the original sound (D)

and the eect sound (W).

Level 0–127 Sets the output volume.

MC-707 Update

MC-707 Update – Functions Added in Ver.1.80

JD Multi

Recreates the eects included in group A of the JD-800.

L inL in

R inR in

L outL out

R outR out

SpectrumSpectrumSpectrumSpectrum

DistortionDistortionDistortionDistortion

PhaserPhaserPhaserPhaser

EnhancerEnhancerEnhancerEnhancer

Parameter Value Explanation

Sequence

DS - PH - SP - EN

Selects the connection order of the eects.

DS: Distortion

PH: Phaser

SP: Spectrum

EN: Enhancer

DS - PH - EN - SP

DS - SP - PH - EN

DS - SP - EN - PH

DS - EN - PH - SP

DS - EN - SP - PH

PH - DS - SP - EN

PH - DS - EN - SP

PH - SP - DS - EN

PH - SP - EN - DS

PH - EN - DS - SP

PH - EN - SP - DS

SP - DS - PH - EN

SP - DS - EN - PH

SP - PH - DS - EN

SP - PH - EN - DS

SP - EN - DS - PH

SP - EN - PH - DS

EN - DS - PH - SP

EN - DS - SP - PH

EN - PH - DS - SP

EN - PH - SP - DS

EN - SP - DS - PH

EN - SP - PH - DS

DS Switch OFF, ON Turns the distortion on/o.

DS Type

Sets the type of distortion.

MELLOW DRV Softer distortion with a slightly darker sound.

OVERDRIVE

Distortion that resembles a vacuum tube amp

being driven.

CRY DRV Distortion that emphasizes the high end.

MELLOW DST

Gives the feeling of distortion playing through a

large amp.

LIGHT DST Strong distortion with a bright sound.

FAT DST

Thick distortion that emphasizes the low and high

ends.

FUZZ DIST

Distortion that’s even more powerful that FAT

DST.

DS Drive 0–100 Sets the amount of distortion.

DS Level 0–100 Sets the distortion output level.

PH Switch OFF, ON Turns the phaser on/o.

PH Manual

50 [Hz]–

15.0 [kHz]

Sets the basic frequency from which the sound is

modulated with the phaser eect.

PH Rate 0.1–10.0 [Hz] Sets the cycle of the phaser modulation.

PH Depth 0–100 Sets the depth of the phaser modulation.

PH Resonance 0–100

Sets the amount of feedback for the phaser.

Increasing the value creates a more unusual

sound.

PH Mix 0–100 Sets the level of the phase-shifted sound.

SP Switch OFF, ON Turns the spectrum on/o.

SP Band Ctrl1 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 250 Hz

range.

SP Band Ctrl2 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 500 Hz

range.

Parameter Value Explanation

SP Band Ctrl3 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 1000

Hz range.

SP Band Ctrl4 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 2000

Hz range.

SP Band Ctrl5 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 4000

Hz range.

SP Band Ctrl6 -15–+15 [dB]

Sets the gain (amount of boost/cut) in the 8000

Hz range.

SP Width 1–5

Sets the bandwidth for changing the levels,

common to all bands.

EH Switch OFF, ON Turns the enhancer on/o.

EH Sens 0–100 Sets how easily the enhancer eect is applied.

EH Mix 0–100

Sets the ratio at which the harmonics generated

by the enhancer are mixed with the original

sound.

Pan L64–63R Changes the pan.

Level 0–127 Sets the output volume.

MULTITRACK Mode Added to PAD NOTE

This function lets you use the MC-707 as an eight-track drum machine.

Hold down the [NOTE] button and press the “>” cursor

button.

This switches NOTE mode to MULTITRACK mode.

This lets you use the upper row of pads (eight buttons) for playing

each track and switching between tracks.

The note produced when you operate the pads or input steps is C4

(60).

Hold down the [NOTE] button and press the “<” cursor

button.

This switches NOTE mode to SINGLE TRACK mode.

MEMOMEMO

You can also edit the settings from “Pad Note Mode”, under the

CTRL tab of SYSTEM SETTING.

Volume Setting Added for WAV File Preview Playback

“WAV Preview Level” has been added to the project settings.
