Sida 1/32

VML

Instruction Manual

We’ll Make It Stress-Free

If you have any questions along the way, just give us a call.

1-800-359-5520 (UK: 0800-056-2853)

We’re ready to help!

Texto en español, página 14

Texte français page 16

Deutscher Text Seiten 18

Nederlandse tekst op pagina 20

Svensk text sida 22

日本語は 24 ページ

中文文字说明请参见第 26 页

Русский текст: стр. 28

IMPORTANT SAFETY INSTRUCTIONS

– SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

—

Perfect!

Yes

—

This mount is NOT compatible. Visit MountFinder.Sanus.com or call

1-800-359-5520 (UK: 0800-056-2853) to ﬁnd a compatible mount.

Please read through these instructions completely to be sure you’re comfortable with this easy install process.

Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use

of this product, contact Customer Service at 1-800-359-5520 (UK: 0800-056-2853).

Do you have all of

the tools needed?

Before getting started, let’s make sure this mount is perfect for you!

What is your

wall made of?

Drywall with

wood studs?

36 kg

(80 lbs)

CAUTION: Avoid potential personal injuries and property damage!

● This product includes directions and hardware for use with wood studs, solid concrete and concrete block walls

– DO NOT install into drywall alone.

● The wall must be capable of supporting ﬁve times the weight of the TV and mount combined.

● Do not use this product for any purpose not explicitly speciﬁed by manufacturer.

● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

Perfect! Perfect!

Ready to begin?

Does your TV weigh

more than 36 kg

(80 lbs) including

accessories?

CAUTION:

DO NOT install

into drywall alone

Solid concrete or

concrete block?

Unsure?

Call Customer Service:

1-800-359-5520

(UK: 0800-056-2853)

Included Wood Stud Applications Concrete Applications

3.2 mm (1/8 in.)

Wood

8 mm (5/16 in.)

Concrete

Screwdriver

Tape

Measure

Stud Finder HammerAwl

Pencil

Drill Bit Drill Bit

Electric

Drill

Square Driver Bit

Produktspecifikationer

Varumärke:	Sanus
Kategori:	väggfäste
Modell:	VML41
Vikt:	1770 g
Bredd:	450.9 mm
Djup:	70.4 mm
Höjd:	40.9 mm
Förpackningens bredd:	481.1 mm
Maximal skärmstorlek:	50 "
Minsta skärmstorlek:	22 "
Avstånd till väggen (min):	70 mm
Lutningsvinkel:	5 - 0 °
Maxvikt:	36.29 kg
Produktens färg:	Svart
Monteringssats:	Ja
Låddjup:	87.9 mm
Material, hölje:	Metall
Monteringssätt:	Vägg
Gränsssnitt för panelmontering:	404 x 404 mm
Antal displayer som stöds:	1
Monteringsgränssnitt kompatibilitet (min):	75 x 75 mm
Monteringsgränssnitt kompatibilitet (max):	75 x 75 mm
