Sanwa MG5000 Bruksanvisning

Sanwa Mätutrustning MG5000

Läs gratis den bruksanvisning för Sanwa MG5000 (28 sidor) i kategorin Mätutrustning. Guiden har ansetts hjälpsam av 27 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 14 recensioner. Har du en fråga om Sanwa MG5000 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/28

MG5000

HIGH VOLTAGE

DIGITAL INSULATION RESISTANCE TESTER

INSTRUCTION MANUAL

Table of Contents

[1]

SAFETY PRECAUTIONS -Before use, read the following safety precautions.–



1-1 Explanation of Warning Symbols 1 .............................................



1-2 Warning Messages for Safe Use 1 .............................................



1-3 Overload Protection 2 .................................................................

[2] APPLICATIONS AND FEATURES



2-1 Applications ............................................................................. 2



2-2 Features ................................................................................... 3

[3] NAMES OF COMPONENT UNITS



3-1 Main unit 3 ..................................................................................



3-2 Display ..................................................................................... 4



3-3 Test leads 4 .................................................................................



3-4 Optional Accessories 5 ...............................................................

[4] DESCRIPTION OF FUNCTIONS



4-1 Power/Function Switch 5 ............................................................



4-2 Starting/Stopping Measurement : TEST Button 5 ......................



4-3 BACKLIGHT Function : LIGHT Button 5 .....................................



4-4 DAR/PI Display Switching : DISPLAY Button 5 ..........................



4-5 Auto Hold 5 .................................................................................



4-6 Auto Power Off 6 ........................................................................



4-7 Battery Monitor 6 ........................................................................

[5] MEASURING PROCEDURE



5-1 Start-up Inspection 7 ..................................................................



5-2 Voltage Measurement : AC/DC V 7 .............................................



5-3 Insulation Resistance Measurement 8 ........................................



5-4 Discharge Function .................................................................11



5-5 DAR/PI Measurement ............................................................ 12



5-6 Voltage Characteristics at Measuring Terminals .................... 14



5-7 Using the GUARD Terminal .................................................... 15

[6] MAINTENANCE



6-1 Maintenance and Inspection.................................................. 15



6-2 Calibration and Inspection ..................................................... 16



6-3 Storage .................................................................................. 16



6-4 Battery Replacement ............................................................. 16

[7] AFTER-SALE SERVICE



7-1 Warranty and Provision ...........................................................17



7-2 Repair ......................................................................................17



7-3 SANWA Website .................................................................... 18

[8] SPECIFICATIONS



8-1 General Specifications ........................................................... 19



8-2 Measuring Ranges and Accuracies ....................................... 20
