1 Product Introduction

1.1 General Introduction

The SARAMONIC SR-AX100 is a 2-channel audio adapter ideal for shooting

videos with any DSLR camera or camcorder. This adapter provides you

with a compact dual-mic mounting and audio mixing solution, which

allows you to easily mount and control two mics or wireless receivers. It

requires no batteries or power source.

1.2 Highlights

1.2.1 Inputs

• One stereo 1/8" (3.5 mm) Mini-Jack Input to connect stereo mic.

• Two mono 1/8" (3.5 mm) Mini-Jack Inputs to connect mono mics.

1.2.2 Output

• One stereo 1/8" (3.5 mm) Mini-Jack outputs audio signal from the

adapter to the camera.

1.2.3 Dual Trim Control Knobs

• Adjust the signal of each channel to the optimum recording levels.

User Manual

SR-AX100

Audio Adapter

The SR-AX100 is a 2-channel audio adapter for shooting

videos with any DSLR camera or camcorder. It provides a

compact dual-mic mounting and audio mixing solution.

1.2.4 Mono /Stereo Switch

• select mono or stereo output mode.

The Mono mode is for one mono microphone recording, it could send

the mono audio signal to each channel and mix them together to output

stereo audio signal.

The Stereo mode is for one stereo microphone or two mono microphones

recording, it provide two separate channels of audio.

1.2.5 Three Integrated Mounting Shoes

• Attach a variety of mics or wireless receivers.

1.2.6 Passive Operation Requires No Batteries

1.2.7 Compact Shaped With Die-cast Aluminum Chassis

1.3 Specifications

Input Level

Gain

Frequency Response

Dimensions

Weight

MIC setting: -35 dBu minimum

Unity

20 Hz to 20 kHz (+/- 0.5 dB)

L 76.0 x W 59.5 x H 55.0 mm

153g ( 5.4 oz. )

Produktspecifikationer

Varumärke:	Saramonic
Kategori:	hi-fi system
Modell:	SR-AX100
Volymkontroll:	Ja
Ljudutgångskanaler:	2 kanaler
Produktens färg:	Black, Red
Kontrolltyp:	Rotations-
Material, hölje:	Plast
Audio ingångskanaler:	1 kanaler
Ljudportstyp:	3,5 mm
