Tachometer
USER MANUAL
Description of the device
1. OK key
2. Backlight key
3. Select key
4. On/Off/Esc key
5. Hold/min/max key
CT 110
Technical specications
Measuring elements
Optical tachometry: optical detection (Phototransistor sighting distance max. 40 cm)
Contact tachometry: ETC adaptator for optical tachometry probe
Display
4 lines, LCD technology. Dimensions: 50 x 36 mm
2 lines of 5 digits with 7 segments (value)
2 lines of 5 digits with 16 segments (unit)
ConnectorCoiled, 0.45 m length, extension: 2.4 m
HousingABS, protection IP54
Keypad5 keys
European directives2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE
Power supply 4 batteries AAA LR03 1.5 V
AmbienceNeutral gas
Conditions of use (°C, %RH, m)From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.
Storage temperature From -20 to +80 °C
Auto shut-offAdjustable from 0 to 120 min
Weight190 g
General features
ParametersMeasuring unitsAccuracy
(1)
Measuring rangeResolution
Optical tachometerrpm
From 60 to 10 000 rpm:
±0.3% of reading ±1 rpm
From 10 001 to 60 000 rpm: ±30 tr/min
From 60 to 60 000 rpm1 rpm
Contact tachometer
rpm, m/min,
ft/min, in/min, m/s
From 30 to 3000 rpm:
±1% of reading ±1 rpm
From 30 to 3000 rpm1 rpm
(1)
All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
