KIRAY 300
Infrared thermometer
USER MANUAL
Spectral response8 - 14 μm
OpticalD.S: 50:1 (50.8 mm at 2540 mm)
Temperature rangeFrom -50 to +1850 °C
Accuracy*
From -50 to +20 °C: ±3 °C
From +20 to +500 °C: ±1% ±1 °C
From +500 to +1000 °C: ±1.5%
From +1000 to +1850 °C: ±2%
Infrared repeatability
From -50 to +20 °C: ±1.5 °C
From +20 to +1000 °C: ±0.5% or ±0.5 °C
From +1000 to +1850 °C: ±1%
Display resolution0.1 °C
Response time150 ms
EmissivityAdjustable from 0.10 to 1.00 (pre-set at 0.95)
Over range indicationDisplay indication: "----"
Dual laser sighting
Wavelength: from 630 nm to 670 nm
Output < 1mW, Class 2 (II)
Positive or negative
temperature indication
Automatic (no indication for a positive temperature)
(-) sign for a negative temperature
Display3 lines, 4 digits with backlighted display LCD
Auto-extinctionAutomatic after 7 seconds of inactivity
High/low alarm
Flashing signal on display and beep signal with
adjustable thresholds
Power supplyAlkaline 9 V battery
Autonomy
95 h (inactive laser and backlight)
15 h (active laser and backlight)
Operating temperature
From 0 to +10 °C for a short period
From 11 to +50 °C for a long period
Storage temperatureFrom -10 °C to +60 °C
Relative humidityFrom 10% to 90%RH in operating mode and >80%RH in storage
Dimensions200 x 140 x 50 mm
Weight320 g (included battery)
Memory100 temperature values
*Accuracy for an ambient temperature from 23 to 25 °C (with a relative humidity lower than 80% RH).
Infrared thermometer Kiray 300 is a thermometer used to diagnose, inspect
and check any temperature. Thanks to its elaborated optical system with a dual
laser sighting, it allows easy and accurate measurements of little distant targets.
The KIRAY 300 instrument has an internal memory which can save up to 100
measurements. Compatible with thermocouple K probe.
Technical specications
°C
°F
Distance from the target
Please make sure that the target is larger than
the size of the laser sighting.
Thermocouple K probe features
Temperature rangeFrom -40 to +400 °C
Display rangeFrom -50 to +1370 °C
Resolution0.1 °C
Accuracy±1.5% of reading ±3 °C
Cable length1 m
Supplied with
thermocouple K
probe
