4’’ diameter

(100 mm)

vane probe

LV 111-110

Vane probe thermo-anemometer

DATA SHEET

ParametersAccuracyMeasuring rangeResolution***

Air velocity

LV111

‘‘ diameter(14 mm)

From 160 to 590 fpm: ±3% of reading value ±20 fpm

(from 0.8 to 3 m/s: ±3% of reading ±0.1 m/s)

From 591 to 4920 fpm: ±1% of reading value ±60 fpm

(from 3.1 to 25 m/s: ±1% of reading ±0.3 m/s)

LV110: 4’’ diameter

(100 mm)

From 60 to 590 fpm: ±3% of reading value ±20 fpm

(from 0.3 to 3 m/s: ±3% of reading ±0.1 m/s)

From 591 to 6890 fpm: ±1% of reading value ±60 fpm

(from 3.1 to 35 m/s: ±1% of reading ±0.3 m/s)

From 160 to 4,920 fpm

(0.8 to 25 m/s)

From 60 to 6,890 fpm

(0.3 to 35 m/s)

1 fpm

(0.1 m/s)

0.1 fpm, 1 fpm

(0.01 m/s, 0.1 m/s)

Airow

All models

±3% of reading ±0.0003 x surface in ft

(±3 % of reading ±0.03 x area in cm²)

From 0 to 58,857 cfm

(0 to 99 999 m³/h)

1 cfm

(1 m³/h)

Temperature

All models

±0.4% of reading ± 0.55 °F

(±0.4 % of reading ±0.3 °C)

From -4 to +176 °F

(-20 to +80 °C)

0.1°F

(0.1 °C)

Features

• Airow calculations

• Integrated temperature sensor

• Selection of units (air velocity, airow

and temperature)

• Congurable auto shut-off

• Detection of ow direction with

the LV 110

• User friendly backlit display

• Compact portable design

Technical specications

Selection of unitsAirow calculation

Automatic averageHold-min-max functions

Supplied with

CALIBRATION

certicate*

*Except class 110 S which is supplied with adjustment certicate.

**3

‘‘ diameter.

***All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
