Sida 1/2
TR 61 - TR 62
Pt100 Thermometers
DATA SHEET
Measuring element Pt100 class A
Number of channels TR61: 1 channel / TR62: 2 channels
Display
4 lines, LCD technology. Dimensions: 1
31
/
32
x 1
13
/
32
’’ (50 x 36 mm)
2 lines of 5 digits with 7 segments (value) / 2 lines of 5 digits with 16 segments (unit)
Housing ABS, protection IP54
Keypad 5 keys
Connector Compensated miniature female connectors
Standards 2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE; FCC part 15
Power supply 4 batteries AAA LR03 1.5 V
Battery life 180 hours
Ambience Neutral gas
Conditions of use °F (°C), %RH, p1-yd (m) From 32 to +122 °F (0 to +50 °C). In non condensing conditions. From 0 to 2188 p1-yd (from 0 to 2000 m)
Storage temperature From -4 to +176 °F (-20 to +80 °C)
Auto shut-off Adjustable from 0 to 120 min
Weight 0.463 lbs (210 g)
(1)
All accuracies indicated in this document were stated in laboratory conditions and can be guaranteed for measurements carried out in the same conditions, or carried out with required compensation.
• Adjustable alarms
• Adjustable backlight
• Hold-min-max function
• Selection of temperature units
• Display of minimum and maximum
values
• Congurable auto shut-off
• Delta temperature (TR62)
Technical specications
°C
°F
Su
AD
certificate
IP54
Pt100 probes (see related data sheet)
Measuring units Measuring range Accuracy
(1)
Resolution
°C, °F
From -148 to +752 °F
(from -100 to +400 °C)
±0.4% of reading ±0.55 °F
(±0.4% of reading ±0.3 °C)
0.1 °F
(0.1 °C)
Specications
Probe(s) not included, sold separately
DS_EN-US – TR61 TR62 – 01/10/24 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Dimensions
TR 61
TR 62
2 63/64’’ / 76.7 mm
1 11/32’’
34.2 mm
2 25/32’’ / 71.5 mm
5 25/32’’ / 147.9 mm
2 63/64’’ / 76.7 mm
Kit content
Instruments are supplied with an adjustment certicate.
Accessories
Description Model
Magnetic protective housing CQ 15
Telescopic extension, 39
3
/
8
’’ (1 m) length,
with index at ±90°
RTE
Pt100 temperature probe -
Black ball Ø5
29
/
32
(150 mm) with stufng box for
temperature probe Ø
3
/
16
”.(4.5 mm)
-
Transport case ST 110
Calibration certicate -
Maintenance
We provide calibration, adjustment, and maintenance for your instruments to ensure consistent measurement quality.
As part of our Quality Assurance Standards, we recommend conducting an annual check-up.
Usage precautions
Always use the device as intended and within the parameters outlined in the technical specications to ensure the protection it provides.
Operating principle
Thermometer: Pt100 Probe
The Pt100 is a resistance sensor with a positive temperature coefcient that changes with temperature.
As the temperature increases, the resistance value also rises.
ie: for 32 °F ≈ 100 Ω
for 212 °F ≈ 138,5 Ω.
sauermanngroup.com
