Sida 1/7
Electronics
The Reexion Filter
Manual
Reexion Filter Technical Manual
SE Electronics Instrument Reexion Filter Manual
Thank you for purchasing the Reexion Filter ‘portable vocal booth’.
The main idea behind this product is to facilitate ‘dry’ vocal recordings, in other words to achieve a vocal
recording which has greatly reduced room ambience. Of course, the same Reexion Filter can be used to
achieve similar results whilst recording various live instruments, for isolating vocals in rehearsal studios
and probably a host of things we haven’t thought of yet too! We’d be very interested to hear about novel
applications from you, so please do contact us with your ideas, we are always glad to listen as it helps us
improve and develop the product, and the information we can supply to other sE users.
Your Reexion Filter carries a 2 year manufacturing warranty, with free replacement of parts in case of
mechanical failure due to faulty components. This warranty does not cover failures deemed to be as a
result of misuse or abuse of the Reexion Filter. If properly used and looked after, it should last a lifetime of
recording use.
You can extend your free 2 year warranty to three years by registering your product at www.seelectronics.
com, so please visit the site and leave your details. You can also subscribe to the sE newsletter which we
email out once every few months (don’t worry, we won’t pass your details on to anyone else, and we won’t
bombard you with SPAM!)
One last thing… please read this assembly manual to get the best results from your Reexion Filter… mic
positioning, and the stand clamp assembly are critical to getting best results.
Thank you again, and we look forward to hearing from you,
Siwei Zou
CEO
sE Electronics International
Reexion Filter Technical Manual
About Your Reexion Filter
What is the Reexion Filter?
The Reexion Filter is basically a portable device for recording live sound sources with reduced room ambience.
It is an advanced composite wall which is positioned behind any microphone by means of a variable position
stand clamp assembly which ships with the product. The main function is to help obtain a ‘dry’ vocal or instrument
recording. This is especially useful in studios without proper acoustic treatment, but can also be used to help
record takes in control rooms, where the performer also has to operate the recording device, or in rehearsal studios
to reduce ambient noise.
The Technical Bit:
The Reexion Filter has 6 main layers. Firstly, a strong layer of punched Aluminium which allows sound waves to
pass through it, diused, to a layer of absorptive wool. The sound waves then hit a layer of Aluminium foil which
helps dissipate energy and break up the lower frequency wave-forms, and from here they hit an air space kept
open by rods passing through the various layers. The air gap acts as an acoustic barrier. The sound waves then pass
to a further layer of wool and then through an outer, punched, Aluminium wall which further serve to absorb then
diuse the remaining acoustic energy.
The main absorber has 4 formed pieces of state-of-the-art specialist acoustic absorptive material attached to its
face via the extended separation rods, which further serve to absorb and then diuse the sound waves as they
pass to the main lter.
The stand assembly comprises a mic stand clamp tting, which attaches by means of a vertical joint to the
horizontal bar assembly onto which both the Reexion Filter, and any standard tting shock mount can be xed.
The microphone (in its shock mount) can then be moved both vertically and horizontally along the bar, and the
Reexion Filter itself can be moved vertically to obtain the optimum working position.
How does it work?
The various layers both absorb and diuse the sound waves hitting them, so progressively less of the original
source acoustic energy passes through each layer. This reduces the amount of energy hitting un-treated walls
and other surfaces so there is less of the original source reected back as unwanted room ambience to the mic.
The Reexion Filter also helps prevent any reected sound reaching the back and sides of the mic. Its shape and
size have been carefully tested to maximize absorption while keeping ‘coloration’ down to only around 1dB, and
leaving the microphone’s polar pattern unaected.
In summary:
All in all, it’s a very clever and desirable piece of kit. It allows you to record vocals, guitars etc with a ‘drier’ sound
without having to have an acoustically treated room. It’s portable. It uses state of the art materials. It works… and
it’s a fraction of the price of acoustically treating your studio environment!
