UR1M Micro Bodypack Transmitter

Addendum

Features:

• SameaudioperformanceasUR1

• Rapidtwo-wayinfrared(IR)datatransmission

• User-adjustableRFoutputlevel(10mWor50mW)

• Operateswiththreetypesofprimarybatteries:

alkaline,lithiumorNiMH

• AudiosignalisinputthroughaTA4Fconnector

(UR1M)oraLEMOconnector(UR1MLEMO3)

• Selectablebatterymeteringbybatterytype

• AudiometeringonUR1Mtransmitter

Specications:

Thefollowingspecicationsapplyto

theUR1Mmicrobodypackonly.

Battery Life (Typical):

Alkaline: 6hours(normalRFpower)

4hours(highRFpower)

Lithium primary: 9hours(normalRFpower)

7hours(highRFpower)

NiMH 1000 mAH: 6hours(normalRFpower)

4hours(highRFpower)

Select Battery Type:

Setthemicrobodypacktransmitterswitchto on

Press key,thenscrollusingenter

buttontoselectbatterytype.Press

enterkeytoconrm.

Note: Forthemostaccuratebatterymeteringandperformance,make

suretoselectthecorrectbatterytype.

Toopenthemicrobodypacktransmitter,seeillustrationsbelow:

Frequency Range

Band Range

G1 470-530MHz

G1E 470-530MHz

H4,H4E 518-578MHz

J5 578-608,614-638MHz

J5E 578-638MHz

K4E 606–666MHz

L3,L3E 638-698MHz

M5E 694–758MHz

P8 710–790MHz

P9 710–787MHz

Q5 740-814MHz

Q6 740-752MHz

Q10A 740-787MHz

R9 790-865MHz

R16,R18 794-806MHz

A24 779-788,797-806MHz

JBX 806-810MHz

X1 944-952MHz

RF Carrier Frequency Range

470-865,944-952MHzdependingonregion

Working Range

150m(500ft.),undertypicalconditions500m

(1600ft.) line-of-sight, outdoors for a single system

NOTE:ActualworkingrangedependsonRFsignalabsorption,reec-

tionandinterference

RF Power Output

Selectable10mWor50mWdependingonregion

Power Requirements:

Two1.5VAAAalkaline,lithiumprimary,andNiMHbatteries

Current Drain:

130mAmax.at3V(normalRFpowersetting)

200mAmax.at3V(highRFpowersetting)

Gain Adjustment Range

–20to+35dB

–10dBrecommendedforguitars

UR1M

27A14979 (Rev. 2)

Printed in U.S.A.

Transmitter LCD Interface and Controls:

ForadditionalinformationontheLCDInterfaceand

controls,seeUHF-RUserGuide.

Slide arrow down

Certication:

UR1M:TypeAcceptedunderFCCParts74(FCCID:DD4UR1MA,DD4UR1MB,DD4UR1MC,DD4UR1MD,DD4UR1MF,DD4UR1MG,DD4UR1MRA,

DD4UR1MRB,DD4UR1MRC,DD4UR1MRG).CertiedbyICinCanadaunderRSS-123andRSS-102(IC:616A-UR1MA,616A-UR1MB,616A-UR1MC,

616A-UR1MD,616A-UR1MG,616A-UR1MRA,616A-UR1MRB,616A-UR1MRC).

TheCEDeclarationofConformitycanbeobtainedfrom:www.shure.com/europe/compliance

LICENSING INFORMATION:

Licensing:Aministeriallicensetooperatethisequipmentmayberequiredincertainareas.Consultyournationalauthorityforpossiblerequirements.

ChangesormodicationsnotexpresslyapprovedbyShureIncorporatedcouldvoidyourauthoritytooperatetheequipment.LicensingofShurewirelessmicro-

phoneequipmentistheuser’sresponsibility,andlicensabilitydependsontheuser’sclassicationandapplication,andontheselectedfrequency.Shurestrongly

urgestheusertocontacttheappropriatetelecommunicationsauthorityconcerningproperlicensing,andbeforechoosingandorderingfrequencies.

Information to User:

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby

turningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

•Relocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

•Consultthedealer

ThisClassBdigitalapparatuscomplieswithCanadianICES-003.

CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

Operationofthisdeviceissubjecttothefollowingtwoconditions:

(1)thisdevicemaynotcauseinterference,and(2)thisdevicemustacceptanyinterference,

includinginterferencethatmaycauseundesired

operationofthedevice.

Note:EMCconformancetestingisbasedontheuseofsuppliedandrecommendedcabletypes.

TheuseofothercabletypesmaydegradeEMCperformance.

SHURE Incorporated http://www.shure.com

United States, Canada, Latin America, Caribbean:

5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A.

Phone: 847-600-2000 U.S. Fax: 847-600-1212 Int’l Fax: 847-600-6446

Europe, Middle East, Africa:

Shure Europe GmbH, Phone: 49-7131-72140 Fax: 49-7131-721414

Asia, Pacific:

Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055

Note

TofullyinteractwiththeReceiver,itisrecommendedtoupgradetheUR4rmwareto1.50orhigherandShureWirelessWorkbenchto5.0

Overall Dimensions

49mmLx60mmWx17mmD(1.9x2.38x0.66in.)

Net Weight

62g(2.2oz.)withoutbatteries

Wiring

TA4FConnector

MicrophoneElement

TA4F

Connector

TA4M

Connector

UR1MMICJACKBOARD

NOTE:LAVALIERMICTIESPINS3AND4TOGETHER—GUITARCABLEDOESNOT.

ActiveLoad

Audio

Ground

LEMOConnector

Connector

UR1MLEMOBOARD

Audio

Ground

MicrophoneElement

UR1M Transmitter RF Output:

Connector: SMA

ActualImpedance: 50Ω

PinAssignments: Shell=Ground

Center=Signal

UR1M Transmitter Audio Input:

Connector: 4-Pinmaleminiconnector(TA4M)

3-Pinfemaleminiconnector(LEMOXRB.00.303)

Input Conguration: Unbalanced,active

Maximum Input Level:

(1 kHz, 1% THD)

+5dBu(sensitivity0dB)

+15dBu(sensitivity–10dB)

TA4M Connector Pin

Assignments:

Pin1:Ground

Pin2:+5VDCbias

Pin3:Audio,200kΩ

Pin4:Tiedthroughactiveload(onmainboard)

toground.

(Oninstrumentadaptercable,Pin4oats)

LEMO Connector Pin

Assignments:

Pin1:Ground

Pin2:+5VDCbias

Pin3:Audio

(8.2kΩbetweenpin2and3,internaltoUR1M)

REPLACEMENT PARTS AND ACCESSORIES

Furnished Accessories

Antenna,470-530MHz.....................................................................UA700

Antenna,518-578MHz.....................................................................UA710

Antenna,578-698MHz....................................................................UA720

Antenna,740-865MHz....................................................................UA730

Antenna,944-952MHz....................................................................UA740

ThreadedLockingAdaptor(UR1MwithTA4F)................................WA340

Optional Accessories

BodypackPouch(Black)............................................................. WA581B

BodypackPouch(White)............................................................. WA581W

3-PinminiLemoconversionkit........................................................WA335
