GeneralDescription

AntennaDistributionSystemssendtheRFsignalfromasinglepairofanten-

nastomultiplereceivers.Ultra-linearamplificationandadjustableattenuation

optimizeperformanceindifficultRFenvironments.Selectableinputfilters

matchtheavailablefrequencybandsoftransmitters,providingextraprotection

fromstrongout-of-bandsignals.BNCantennaoutputpairsdistributeband-

filteredsignalstoupto4receivers.Apairofwidebandcascadeportssupply

widebandRFsignalstoSpectrumManagersoradditionalantennadistribution

amplifiers.NetworkingallowsWirelessWorkbenchtocontrolfilteringranges

andattenuation.Foraddedflexibility,AxientAntennaDistributionSystems

arecompatiblewithShureULX-DandUHF-Rreceivers.

TomaximizeuseoftheRFspectrum,AntennaDistributionSystemsare

availableinthefollowingfrequencyranges:

•(470-698MHz)AXT630

•(606-814MHz)AXT631

•(470-510MHzand630-787MHz)AXT632

Note:InstructionsinthissystemguideapplyallmodelsofAxientAntenna

DistributionsSystems.

Features

•Selectableinputfilteringprovidessystem-wideprotectionagainststrong

out-of-bandsignals

•Widebandfilteringoptioncoversmultiplebands

•Upto15dBofselectableRFattenuationforsignal-to-noiseoptimization

•FrontpanelinterfaceandWirelessWorkbench6softwarecontrolprovide

easysetupandcontroloffiltering,antennapower,andattenuation

•BNCoutputs:4antennaoutputpairs

•WidebandRFcascadeportwithselectable3dBmake-upgainforcon-

nectingwidebanddevices

•EthernetNetworking:2PoEenabledEthernetports

•IECpowerportsenabledaisy-chainingofACpower

MountingInstructions

Thiscomponentisdesignedtofitintoanaudiorack.

WARNING:Topreventinjurythisapparatusmustbesecurelyattachedto

therack.

ControlsandConnectors

power

SET

23

1

AXT631

606-814 MHz

Antenna Distribution

antenna

in

BA

4

56

8

79

10

11

12

14

13

AXT631

4B3B2B1B

RF outputs

4A3A2A1A

RF outputs

PoE Class 1

①LCDDisplay

Displaysmenuandsettings.

②NavigationButtons

•Arrows:Scrollmenusandchangesettings

•Set:Enablesmenueditsandsaveschanges

Tip:Pressandholdthebuttonfor1secondtoactivatetheHardwareIdentifyfeatureinWirelessWorkbench.Set

1/9©2017ShureIncorporated

AXT630

Antenna Distribution System
