LN-554

User Manual

Table of Contents

Introduction .......................................................................................................... 3

Package Contents .................................................................................................. 4

Cautions ............................................................................................................... 5

Product Layout ...................................................................................................... 6

Connecting the Homeplug ....................................................................................... 8

Configuring the device ..........................................................................................11

Addendum: Declaration of Conformity .....................................................................26

Revision 1.2

Note: All the information contained in this manual was correct at the time of publication.

However, as our engineers are always updating and improving the product, your device’s

software may have a slightly different appearance or modified functionality than

presented in this manual.

Introduction

Homeplug is home and office networking using the electric wiring already installed in the

building.

Cost factor and transmission quality

Homeplug is an economical and easy-to-use networking technology. You don't need to

lay cables and you can connect to the home network at every power point.

The Homeplug standard modulates and demodulates additional frequencies on the power

lines. Modulation and demodulation is a well-known and proven method of data

transmission, which has been in use in other applications for a number of years. Now it is

used to set up Internet and network accesses in the home or office. Depending on the

damping factor, distances of at least 200 meters can be covered.

With a maximum data rate up to 500 Mbps and symmetrical upload and download

speeds, Homeplug is comparable to traditional Ethernet network solutions.

Data security and radiation

128-bit AES encryption is used, which guarantees secure data transfer within the

network.

WiFi

Not only is the LN-554 very compact, it is designed with a built-in power adapter. This

design allows you to plug it directly into an electrical outlet, eliminating the need for an

additional power cable. You can easily install it where your Wi-Fi signal needs

enhancement and enjoy high-speed wireless performance without any hassles.

The latest 802.11n technology is built into the LN-554 to broaden its wireless coverage

and to eliminate dead spots within the wireless range. The LN-554 complies with wireless

802.11b/g/n standards and can reach data transmission rates of up to 300Mbps when

connected to wireless 802.11n devices. It provides faster and more reliable wireless

connections than standard 802.11b/g wireless networks.

This product can be used safely in the countries listed below:

Produktspecifikationer

Varumärke:	Sitecom
Kategori:	Powerline adapter
Modell:	LN-554
Vikt:	194 g
Bredd:	85 mm
Djup:	60 mm
Höjd:	105 mm
LED-indikatorer:	Data, LAN, Power, Y
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Certifiering:	FCC, CE EMC B, UL, CE LVD
Snabbinstallationsguide:	Ja
Maximal dataöverföringshastighet:	500 Mbit/s
Produktens färg:	Vit
Antal per förpackning:	1 styck
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Ja
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Antal LAN (RJ-45) anslutningar:	2
Strömförbrukning (vanlig):	6.5 W
Hållbarhetscertifiering:	RoHS
AC-inspänning:	220-240 V
Kryptering/säkerhet:	128-bit AES, 128-bit WEP, 64-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2
Kabel inkluderad:	LAN (RJ-45)
Nätverksansluten (Ethernet):	Ja
Modulator:	1024-QAM, 16-QAM, 256-QAM, 4096-QAM, 64-QAM, 8-QAM, BPSK, OFDM, QPSK, ROBO
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3u
Inbyggd eluttag:	Nej
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Plug & Play-kompatibel:	Ja
Typ av Ethernet LAN-gränssnitt:	Snabb Ethernet
Linux operativsystem som stöds:	Ja
Tillgängliga dataöverföringshastigheter, WLAN:	300 Mbit/s
Wi-Fi-standard:	Wi-Fi 4 (802.11n)
PowerLine-standard:	HomePlug AV
Kryptering knapp:	Ja
