Sida 1/62

WLR-1000/2000/3000

Wireless Broadband Router

(802.11b/g/n)

User Manual

ABLE OF

ONTENTS

KEY FEATURES......................................................................................................................... 4

PACKAGE CONTENTS............................................................................................................. 5

PRODUCT LAYOUT.................................................................................................................. 6

NETWORK + SYSTEM REQUIREMENTS............................................................................ 9

WLR-1000/2000/3000 PLACEMENT........................................................................................ 9

SETUP LAN, WAN.................................................................................................................... 10

PC NETWORK ADAPTER SETUP (WINDOWS XP)............................................................11

BRING UP WLR-1000/2000/3000 ............................................................................................ 15

INITIAL SETUP WLR-1000/2000/3000 .................................................................................. 15

CONFIGURATION WIZARD................................................................................................. 24

WIRELESS SETTINGS............................................................................................................ 26

FIREWALL SETTINGS ........................................................................................................... 36

ADVANCED SETTINGS.......................................................................................................... 42

TOOLBOX SETTINGS ............................................................................................................ 52

Revision:1.1

Introduction

Congratulations on your purchase of the WLR-1000/2000/3000 Wireless

Network Broadband Router. The WLR-1000/2000/3000 is compliant with

802.11n and up to 6 times faster than standard 802.11g based routers while

still being compatible with 802.11g & 802.11b. The WLR-1000/2000/3000 is

not only a Wireless Access Point, but also doubles as a 4-port full-duplex

Switch that connects your wired-Ethernet devices together.

At 300 Mbps (150 Mbps for the WLR-1000) wireless transmission rate, the

Access Point built into the Router uses advanced MIMO (Multi-Input, Multi-

Output) technology to transmit multiple steams of data in a single wireless

channel, giving you seamless access to multimedia content. Robust RF signal

travels farther, eliminates dead spots and extends network range. For data

protection and privacy, the WLR-1000/2000/3000 encodes all wireless

transmissions with WEP, WPA, and WPA2 encryption.

With the inbuilt DHCP Server & powerful SPI firewall, the WLR-

1000/2000/3000 protects your computers against intruders and most known

Internet attacks but provides safe VPN pass-through. With incredible speed

and QoS function of 802.11n(draft2.0), the WLR-1000/2000/3000 is ideal for

media-centric applications like streaming video, gaming, and VoIP telephony

to run multiple media-intense data streams through the network at the same

time, with no degradation in performance.

Produktspecifikationer

Varumärke:	Sitecom
Kategori:	Router
Modell:	WLR-3000
Vikt:	- g
Återställningsknapp:	Ja
Frekvensomfång:	2.4
Universal Plug and Play (UPnP):	Ja
Produktens färg:	Grå
bruksanvisning:	Ja
Nätverksegenskaper:	Snabb Ethernet
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Antal LAN (RJ-45) anslutningar:	4
Produktstorlek (BxDxH):	- mm
Kryptering/säkerhet:	128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA-AES, WPA-TKIP, WPA2
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	PPPoE / PPTP
Likströmsingång:	Ja
Firmware kan uppgraderas:	Ja
AC-adapter inkluderad:	Ja
Antenner mängd:	3
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3i, IEEE 802.3u
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Typ av Ethernet LAN-gränssnitt:	Snabb Ethernet
Tillgängliga dataöverföringshastigheter, WLAN:	300 Mbit/s
Dataöverföringshastighet via WLAN (max):	300 Mbit/s
