4KWALL-UHD
UHD HDMI 2x2 video wall controller and 4x4 matrix switch
USER MANUAL
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
UHD HDMI 2x2 Video Wall Controller and 4x4 Matrix Switch 2
OVERVIEW
TECHNICAL SPECIFICATIONS___________________________________________________________________________
WHAT’S IN THE BOX?_____________________________________________________________________________________
FRONT AND BACK________________________________________________________________________________________
INTRODUCTION___________________________________________________________________________________________
FEATURES__________________________________________________________________________________________________
APPLICATION_____________________________________________________________________________________________
INSTALLATION____________________________________________________________________________________________
AVAILABLE CONFIGURATIONS__________________________________________________________________________
CONTROL USING FRONT PANEL_________________________________________________________________________
CONTROL VIA ETHERNET (TCP/IP)______________________________________________________________________
CONTROL USING RS-232 CONTROL____________________________________________________________________
RS-232 COMMANDS______________________________________________________________________________________
CONTROL USING IR REMOTE CONTROL________________________________________________________________
TROUBLESHOOTING____________________________________________________________________________________
TECHNICAL SUPPORT____________________________________________________________________________________
LIMITED WARRANTY STATEMENT______________________________________________________________________
3
3
3
4
4
4
5
6
7
8-9
9-10
11
11
12
12
13
UHD HDMI 2x2 Video Wall Controller and 4x4 Matrix Switch 3
Technical Specifications
VIDEO
Format HDMI 2.0
Input Resolution Up to 3840x2160 @60 Hz
Output Resolution Up to 3840x2160 @60 Hz
Input Interface (4) HDMI 19-pin (female)
Output Interface (4) HDMI 19-pin (female)
AUDIO
Format HDMI Digital Audio
CONTROL
Front Panel Push Buttons
IR Remote Control IR RC5
Ethernet (TCP/IP) RJ-45
RS-232 DB9 (female)
OTHER
Power Adapter 12VDC3A
Dimensions 13”W x 9”H x 1.9”D
Weight 4.8 lbs
Approvals UL, CE, ROHS Compliant
Operating Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensation)
Emulation Keyboard and Mouse
What’s in the box?
FRONT AND BACK
PART NO. Q-TY DESCRIPTION
4KWALL-UHD 1 UHD HDMI 2x2 video wall controller and 4x4 matrix switch
PS5VDC3A 1 12V DC 3A (minimum) power adapter with center-pin positive polarity
1 User Manual
4KWALL-UHD Back Panel
4KWALL-UHD Front Panel
