Sida 1/12

SM-MST SERIES

MST DP KVM with MULTIPLE 4K HDMI Out

USER MANUAL

Designed and Manufactured in the USA

1-800-284-2131

www.smartavi.com

SM-MST-2D 2-Port KVM MST with Dual 4K HDMI Out

SM-MST-2Q 2-Port KVM MST with Quad 4K HDMI Out

SM-MST-4D 4-Port KVM MST with Dual 4K HDMI Out

SM-MST-4Q 4-Port KVM MST with Quad 4K HDMI Out

2/4 Port KVM MST with Dual or Quad 4K HDMI Out 2

OVERVIEW

TECHNICAL SPECIFICATIONS_________________________________________________________________

WHAT’S IN THE BOX?_________________________________________________________________________

FRONT AND BACK___________________________________________________________________________

INSTALLATION_______________________________________________________________________________

SYSTEM OPERATION_________________________________________________________________________

FRONT PANEL CONTROL_____________________________________________________________________

HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________

CUSTOM HOTKEY TRIGGERS_________________________________________________________________

LED’S BEHAVIOUR___________________________________________________________________________

TROUBLESHOOTING_________________________________________________________________________

TECHNICAL SUPPORT________________________________________________________________________

LIMITED WARRANTY STATEMENT____________________________________________________________

5-6

2/4 Port KVM MST with Dual or Quad 4K HDMI Out 3

Technical Specifications

VIDEO

Format DisplayPort1.2a

Input Interface

SM-MST-2S (2) DisplayPort1.2a

SM-MST-2D / SM-MST-4S (4) DisplayPort1.2a

SM-MST-2S (8) DisplayPort1.2a

Output Interface

SM-MST-2S / SM-MST-4S (2) HDMI

SM-MST-2D / SM-MST-4D (4) HDMI

Resoluon Up to 4K (3840 x 2160 @ 30 Hz)

DDC 5 volts p-p (TTL)

Input Equalizaon Automac

Input Cable Length Up to 20 

Output Cable Length Up to 20 

AUDIO

Input Interface (2) 3.5 mm Stereo Audio

Output Interface (1) 3.5 mm Stereo Audio

Impedance 600 Ohm

Frequency Response 20 Hz to 20 kHz

Nominal Level 0-1.0 V

Common Mode Rejecon at 60 dB

USB

Input interface (TX) (2) USB type B

Output interface (RX)

(2) USB 1.1 Type A for KM Devices

(2) USB 2.0 Type A Transparent

Emulaon USB 1.1 and USB 2.0 Compable

CONTROL

Front Panel Push Buons with LED Indicators

RS-232 DB9 Female - 115200 N,8,1, No ow control

Hot Keys Via Keyboard

OTHER

Power Adapter External 100-240 VAC/ 12VDC2A @ 24 W

Approvals UL, CE, ROHS Compliant

Operang Temperature +32 to +104°F (0 to +40°C)

Storage Temperature -4 to 140°F (-20 to +60°C)

Humidity Up to 80% (No Condensaon)

Produktspecifikationer

Varumärke:	Smart-AVI
Kategori:	brytare
Modell:	SM-MST-2Q
Inbyggd display:	Nej
Vikt:	1746.3 g
Bredd:	223.5 mm
Djup:	168.9 mm
Höjd:	66.8 mm
LED-indikatorer:	Ja
Maximal upplösning:	3840 x 2160 pixlar
Antal HDMI-portar:	4
USB-anslutning:	USB Type-A, USB Type-B
Rackmontering:	Nej
DisplayPort-version:	1.2a
Antal datorer:	2
Videobandbredd:	60 hz
Ljudanslutningar:	Ja
Produktens färg:	Svart
HD-typ:	4K Ultra HD
Antal displayportar:	4
Strömförbrukning (vanlig):	24 W
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 80 %
Seriella portar:	1
Video porttyp:	HDMI/DisplayPort
Strömkälla:	AC
Ingående ström:	2 A
Tangentbord anslutningstyp:	USB
Mus porttyp:	USB
Typ av serieport:	RS-232
