Contents

1 Instructions 38

1.1 General safety instructions 38

1.2 Identification plate 42

1.3 Manufacturer liability 42

1.4 Appliance purpose 43

1.5 This user manual 43

1.6 Disposal 43

1.7 How to read the user manual 44

2 Description 45

2.1 General Description 45

2.2 Cooking hob 45

2.3 Control panel 46

2.4 Other parts 47

2.5 Available accessories 48

3 Use 49

3.1 Instructions 49

3.2 First use 50

3.3 Using the accessories 50

3.4 Using the hob 51

3.5 Using the storage compartment 55

3.6 Using the oven 55

3.7 Cooking advice 57

4 Cleaning and maintenance 60

4.1 Instructions 60

4.2 Cleaning the appliance 60

4.3 Removing the door 61

4.4 Cleaning the door glazing 62

4.5 Removing the internal glass panes 62

4.6 Cleaning the inside of the oven 63

4.7 Extraordinary maintenance 64

5 Installation 66

5.1 Electrical connection 66

5.2 Positioning 67

5.3 Instructions for the installer 70

We advise you to read this manual carefully, as it contains all the instructions for maintaining

the appliance’s aesthetic and functional qualities.

For further information on the product: www.smeg.com

Instructions

1 Instructions

1.1 General safety instructions

Risk of personal injury

• During use the appliance and its

accessible parts become very hot.

Never touch the heating elements

during use.

• Protect your hands by wearing

oven gloves when moving food

inside the oven.

• Never try to put out a fire or flames

with water: turn off the appliance

and smother the flames with a fire

blanket or other appropriate

cover.

• This appliance may be used by

children aged at least 8 and by

people of reduced physical,

sensory or mental capacity, or

lacking in experience in the use of

electrical appliances, provided

that they are supervised or

instructed by adults who are

responsible for their safety.

• Children must never play with the

appliance.

• Keep children under the age of 8

at a safe distance unless they are

constantly supervised.

• Keep children under the age of 8

away from the appliance when it

is in use.

• Cleaning and maintenance must

not be carried out by

unsupervised children.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• Fats and oils can catch fire if they

overheat. Do not leave the

appliance unattended while

preparing foods containing oils or

fats. If fats or oils catch fire, never

put water on them. Place the lid

on the pan and turn off the

relevant cooking zone.

• Cooking process should always

be kept under control. A short

cooking process must be

continuously surveyed.

Instructions

• While cooking do not place metal

objects, such as cutlery or dishes

on the hob surface as they may

overheat.

• Do not insert pointed metal objects

(cutlery or utensils) into the slots in

the appliance.

• Do not pour water directly on very

hot trays.

• Keep the oven door closed during

cooking.

• If you need to move food or at the

end of cooking, open the door 5

cm for a few seconds, let the

steam come out, then open it fully.

• Do not open the storage

compartment (where present)

when the oven is on and still hot.

• The items inside the storage

compartment could be very hot

after using the oven.

• DO NOT USE OR STORE

FLAMMABLE MATERIALS IN

THE STORAGE

COMPARTMENT (IF AVAILABLE)

OR NEAR THE APPLIANCE.

• DO NOT USE AEROSOLS IN

THE VICINITY OF THIS

APPLIANCE WHILST IT IS IN

USE.

• Switch off the appliance after use.

• DO NOT MODIFY THIS

APPLIANCE.

• Before any operation on the

appliance (installation,

maintenance, positioning or

movement) always wear PPM.

• Before performing any operation

on the appliance, switch off the

power supply.

• Have qualified personnel carry out

installation and assistance

interventions according to the

standards in force.

• Do not try to repair the appliance

yourself or without the intervention

of a qualified technician.

• Do not pull the cable to remove

the plug.

• If the power supply cable is

damaged, contact technical

support immediately and they will

replace it.

Produktspecifikationer

Varumärke:	Smeg
Kategori:	Ugn
Modell:	CX60ISV9
Produkttyp:	Fristående köksspis
Inbyggd display:	Nej
Vikt:	47800 g
Bredd:	600 mm
Djup:	600 mm
Höjd:	860 mm
Grill:	Ja
Antal funktioner:	6
Konvektionsmatlagning:	Ja
Höjd (min):	840 mm
Ugnens strömkälla:	Elektrisk
Antal ugnar:	1
Energiförbrukning (konventionell):	0.99 kWh
Ugnsstorlek:	Medium
Ugnens termostatområde:	50 - 260 ° C
Självrengörande:	Ja
Övervärme:	Ja
Förvaringsfack:	Ja
Grill med fläkt:	Ja
Produktens färg:	Rostfritt stål
bruksanvisning:	Ja
Kontrolltyp:	Rotary, Touch
Wok brännare:	Nej
Ugnens bruttokapacitet:	79 l
Ugnens nettokapacitet:	70 l
Antal nivåer:	5
Rengöringstyp:	Ånga
AC-inspänning:	220 - 240 V
Material, hölje:	Rostfritt stål
Växelström Frekvens:	50 - 60 hz
Energieffektivitetsskalning:	A+++ till D
Ström:	43 A
Tittfönster:	Ja
Grill styrka:	2700 W
Inbyggd lampa:	Ja
Typ av spishäll:	Induktionshäll med zon
Antal brännare / zoner matlagning:	4
Antalet elektriska kokzoner:	4
Diameter på platta/tillagningsyta 1:	200 mm
Placering av platta/tillagningsyta 4:	Höger fram
Typ av platta/tillagningsyta 4:	Liten
Typ av platta/tillagningsyta 3:	Medium
Placering av platta/tillagningsyta 3:	Höger bak
Strömförsörjning till platta/tillagningsyta 3:	Elektrisk
Diameter på platta/tillagningsyta 4:	160 mm
Typ av platta/tillagningsyta 1:	Medium
Placering av platta/tillagningsyta 2:	Vänster bak
Diameter på platta/tillagningsyta 2:	160 mm
Diameter på platta/tillagningsyta 3:	200 mm
Strömförsörjning till platta/tillagningsyta 4:	Elektrisk
Strömförsörjning till platta/tillagningsyta 2:	Elektrisk
Typ av platta/tillagningsyta 2:	Liten
Strömförsörjning till platta/tillagningsyta 1:	Elektrisk
Placering av platta/tillagningsyta 1:	Främre till vänster
Manöverplats:	Framsida
Maximal kabelförlust med anslutning:	Ja
Effekt på platta/tillagningsyta 1:	2300 W
Effekt på platta/tillagningsyta 2:	1300 W
Effekt på platta/tillagningsyta 3:	2300 W
Effekt på platta/tillagningsyta 4:	1300 W
Topp och undervärme:	Ja
Normalkokning:	Ja
Energiförbrukning (påtvingad konvektion):	0.8 kWh
Anslutningseffekt (elektrisk):	9800 W
Handtagets färg:	Rostfritt stål
Invändigt ytskikt:	Emalj
Antal kokzoner som kan användas samtidigt:	4
Ugnens dörröppning:	Nedfällbar öppning
Bottenvärme:	Ja
Ugnens placering:	Botten
Löstagbar ugnslucka:	Ja
Antal glaspaneler dörr:	3
Klar larm:	Ja
Förvaringsutrymmets placering:	Botten
Typ av förvaringsutrymme:	Förvaringslåda
Topp, botten och fläkt:	Ja
Material i ugnens dörr:	Glas
Löstagbart glas i ugnsluckan:	Ja
