Table of contents

1 Instructions 52

1.1 General safety instructions 52

1.2 Manufacturer liability 57

1.3 Appliance purpose 57

1.4 Identification plate 57

1.5 This user manual 57

1.6 Disposal 57

1.7 To save energy 58

1.8 How to read the user manual 59

2 Description 60

2.1 General Description 60

2.2 Cooking hob 61

2.3 Control panel 62

2.4 Other parts 62

2.5 Available accessories 63

3 Use 64

3.1 Using the accessories 66

3.2 Using the hob 66

3.3 Using the oven 73

3.4 Cooking advice 74

3.5 Programmer clock 76

4 Cleaning and maintenance 81

4.1 Cleaning the hob 82

4.2 Cleaning the door 83

4.3 Cleaning the oven cavity 85

4.4 Vapor Clean 86

4.5 Extraordinary maintenance 87

5 Installation 89

5.1 Positioning 89

5.2 Electrical connection 94

5.3 Instructions for the installer 96

We advise you to read this manual carefully, as it contains all the instructions for maintaining

the appliance’s aesthetic and functional qualities.

For further information on the product: www.smeg.com

TRANSLATION OF THE ORIGINAL INSTRUCTIONS

Instructions

1 Instructions

1.1 General safety instructions

Risk of personal injury

• During use the appliance and its

accessible parts become very hot.

Never touch the heating elements

during use.

• Protect your hands by wearing

oven gloves when moving food

inside the oven.

• Never try to put out a fire or

flames with water: turn off the

appliance and smother the flames

with a fire blanket or other

appropriate cover.

• This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand the

hazards involved.

• Children must not play with the

appliance.

• Keep children under the age of 8

at a safe distance unless they are

constantly supervised.

• Keep children under the age of 8

away from the appliance when it

is in use.

• Cleaning and maintenance must

not be carried out by

unsupervised children.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• Fats and oils can catch fire if they

overheat. Do not leave the

appliance unattended while

preparing foods containing oils or

fats. If fats or oils catch fire, never

put water on them. Place the lid

on the pan and turn off the

relevant cooking zone.

• The cooking process must always

be monitored. A short cooking

process must be continuously

surveyed.

• While cooking do not place

metal objects, such as cutlery or

dishes on the hob surface as they

may overheat.

Instructions

• Do not insert pointed metal

objects (cutlery or utensils) into the

slots in the appliance.

• Do not pour water directly on very

hot trays.

• Keep the oven door closed

during cooking.

• If you need to move food or at the

end of cooking, open the door

5 cm for a few seconds, let the

steam come out, then open it fully.

• Do not open the storage

compartment (where present)

when the oven is on and still hot.

• The items inside the storage

compartment could be very hot

after using the oven.

• DO NOT USE OR STORE

FLAMMABLE MATERIALS IN

THE STORAGE

COMPARTMENT (IF AVAILABLE)

OR NEAR THE APPLIANCE.

• DO NOT USE AEROSOLS IN

THE VICINITY OF THIS

APPLIANCE WHILST IT IS IN

USE.

• Switch off the appliance

immediately after use.

• DO NOT MODIFY THIS

APPLIANCE.

• Always use any necessary/

required personal protective

equipment (PPE) before

performing any work on the

appliance (installation,

maintenance, positioning or

movement).

• Before performing any operation

on the appliance, switch off the

power supply.

• Have qualified personnel carry

out installation and assistance

interventions according to the

standards in force.

• Do not try to repair the appliance

yourself or without the intervention

of a qualified technician.

• Do not pull the cable to remove

the plug.

• In order to avoid hazard, if the

power supply cable is damaged,

contact technical support and

they will replace it.
