Contents

1 Instructions 4

1.1 General safety instructions 4

1.2 Manufacturer liability 7

1.3 Appliance purpose 7

1.4 Disposal 8

1.5 Identification plate 8

1.6 This user manual 8

1.7 How to read the user manual 9

2 Description 10

2.1 General Description 10

2.2 Symbols 11

3 Use 12

3.1 Instructions 12

3.2 First use 13

3.3 Using the cooktop 13

4 Cleaning and maintenance 16

4.1 Instructions 16

4.2 Cleaning the appliance 16

5 Installation 18

5.1 Clearances above and around domestic appliances 18

5.2 Safety instructions 19

5.3 Section cut from the work surface 20

5.4 Mounting 22

5.5 Fixing using brackets 23

5.6 Gas connection 24

5.7 Adaptation to different types of gas 27

5.8 Electrical connection 31

5.9 Instructions for the installer 32

We advise you to read this manual carefully, as it contains all the instructions for maintaining

the appliance’s aesthetic and functional qualities.

For further information on the product: www.smeg.com 02 8667 4833

These instructions apply only to the destination countries listed on the appliance's data

plate.

This is a class 3 built-in hob.

Instructions

1 Instructions

1.1 General safety instructions

Risk of personal injury

• During use the appliance and its

accessible parts become very hot.

Never touch the heating elements

during use.

• Never try to put out a fire or flames

with water: turn off the appliance

and smother the flames with a fire

blanket or other appropriate

cover.

• This appliance may be used by

children aged at least 8 and by

people of reduced physical,

sensory or mental capacity, or

lacking in experience in the use of

electrical appliances, as long they

are supervised or instructed by

adults who are responsible for

their safety.

• Children must not be allowed to

play with the appliance.

• Keep children under eight years of

age at a safe distance if they are

not constantly supervised.

• Do not allow children younger

than 8 years old to come near the

appliance when in operation.

• Cleaning and maintenance must

not be carried out by unsupervised

children.

• Make sure that the flame-spreader

crowns are correctly positioned in

their housings with their respective

burner caps.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• Fats and oils can catch fire if they

overheat. Do not leave the

appliance unattended while

preparing foods containing oils or

fats. If fats or oils catch fire, never

put water on them. Place the lid on

the pan and turn off the relevant

cooking zone.

• The cooking process must always

be monitored. Short cooking

processes must be monitored

continuously.

• When in use, do not place metal

objects, such as dishes or cutlery,

on the surface of the cooktop as

they may overheat.

• Do not insert pointed metal objects

(cutlery or utensils) into the slots in

the appliance.

• DO NOT USE OR STORE

FLAMMABLE MATERIALS NEAR

THE APPLIANCE.

• NEVER USE AEROSOL CANS

NEAR THE APPLIANCE WHILE IT

IS IN OPERATION.

Instructions

• Switch the appliance off

immediately after use.

• DO NOT MODIFY THIS

APPLIANCE.

• Before carrying out any work on

the appliance (installation,

maintenance, positioning or

moving), wear personal protective

equipment.

• Before carrying out any work on

the appliance, disconnect the

mains power supply.

• Have authorised persons carry out

installation and assistance

interventions according to the

standards in force.

• Do not try to repair the appliance

yourself or without the intervention

of authorised persons.

• Do not pull the cable to remove

the plug.

• If the power supply cable is

damaged, contact technical

support immediately and they will

replace it.

Risk of damaging the appliance

• Use wooden or plastic utensils.

• Do not seat on the appliance.

• Do not use steam jets to clean the

appliance.

• Do not obstruct ventilation

openings and heat dispersal slots.

• Never leave the appliance

unattended during cooking

operations in which fats or oils

could be released that could

overheat and catch fire. Be very

careful.

• Never leave objects on the

cooking surface.

• DO NOT USE THE APPLIANCE

TO HEAT ROOMS FOR ANY

REASON.

• Do not spray any spray products

near the oven.

• Do not use plastic kitchenware or

containers when cooking food.

• All cookware must have smooth,

flat bottoms.

• If any liquid does boil over or spill,

remove the excess from the

cooktop.

• Take care not to spill acidic

substances such as lemon juice or

vinegar onto the cooktop.

• Do not put empty pans or frying

pans on switched on cooking

zones.

• Do not use steam jets to clean the

appliance.

• Do not use rough or abrasive

materials or sharp metal scrapers.

Produktspecifikationer

Varumärke:	Smeg
Kategori:	Ugn
Modell:	PX375
Inbyggd display:	Nej
Bredd:	725 mm
Djup:	510 mm
Höjd:	40 mm
Elektronisk tändning:	Ja
Antal gasbrännare:	5
Ramtyp:	Utan ram
Produktens färg:	Black, Stainless steel
Kontrolltyp:	Rotations-
AC-inspänning:	220 - 240 V
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 / 60 hz
Installationsfack, bredd:	560 mm
Installationsfack, djup:	482 mm
Installationsfack, höjd:	41 mm
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	5
Kokzon 3, form:	Rund
Placering av platta/tillagningsyta 4:	Höger bak
Typ av platta/tillagningsyta 4:	Vanlig
Typ av platta/tillagningsyta 3:	Extra stor
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Central
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Typ av platta/tillagningsyta 1:	Stor
Placering av platta/tillagningsyta 2:	Främre till vänster
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Sjudning
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster bak
Sjuda brännare / kokzon:	1100 W
Regelbunden brännare / kokzon:	1800 W
Stora brännare / kokzon:	2600 W
Manöverplats:	Framsida
Effekt på platta/tillagningsyta 1:	2600 W
Effekt på platta/tillagningsyta 2:	1100 W
Effekt på platta/tillagningsyta 3:	4000 W
Extra stor hög hastighet brännare / kokzon:	4000 W
Effekt på platta/tillagningsyta 4:	1800 W
Typ av ytskikt:	Rostfritt stål
Lätt att rengöra:	Ja
Anslutningseffekt (elektrisk):	- W
Installation fack djup (min):	478 mm
Installation fack djup (max):	482 mm
Anslutningseffekt (gas):	11300 W
Effekt på platta/tillagningsyta 5:	1800 W
Typ av platta/tillagningsyta 5:	Vanlig
Kokzon 5, form:	Rund
Placering av platta/tillagningsyta 5:	Höger fram
Strömförsörjning till platta/tillagningsyta 5:	gas
Spisens bredd, storlek:	73 cm
Hällskydd för spishäll:	Nej
Integrerad huva:	Nej
