Washing Machine

User’s Manual

SWE86-1

SWE106D-1

2 / EN

Washing Machine / User’s Manual

1 Important instructions for safety and

environment

This section contains safety instructions that will help protect

from risk of personal injury or property damage. Failure to

follow these instructions shall void any warranty.

1.1 General safety

• Thisproductcanbeusedbychildrenatandabove8

yearsoldandbypersonswhosephysical,sensoryor

mentalcapabilitieswerenotfullydevelopedorwho

lack experience and knowledge provided that they are

supervised or trained on the safe usage of the product

andtherisksitbringsout.Childrenmustnotplaywith

theproduct.Cleaningandmaintenanceworksshouldnot

beperformedbychildrenunlesstheyaresupervisedby

someone.

• Neverplacetheproductonacarpet-coveredfloor.

Otherwise,lackofairflowbeneaththemachinewillcause

electricalpartstooverheat.Thiswillcauseproblemswith

your product.

• Iftheproducthasafailure,itshouldnotbeoperated

unlessitisrepairedbytheAuthorizedServiceAgent.

There is the risk of electric shock!

• Thisproductisdesignedtoresumeoperatingintheevent

ofpoweringonafterapowerinterruption.Ifyouwishto

canceltheprogramme,see"Cancellingtheprogramme"

section.

• Connecttheproducttoagroundedoutletprotected

bya16Afuse.Donotneglecttohavethegrounding

installationmadebyaqualifiedelectrician.Ourcompany

shallnotbeliableforanydamagesthatwillarisewhen

the product is used without grounding in accordance with

the local regulations.

• Thewatersupplyanddraininghosesmustbesecurely

fastenedandremainundamaged.Otherwise,thereisthe

risk of water leakage.

• Neveropentheloadingdoororremovethefilterwhile

thereisstillwaterinthedrum.Otherwise,riskofflooding

and injury from hot water will occur.

• Donotforceopenthelockedloadingdoor.Theloading

doorwillbereadytoopenjustafewminutesafterthe

washingcyclecomestoanend.Incaseofforcingthe

loadingdoortoopen,thedoorandthelockmechanism

may get damaged.

• Unplugtheproductwhennotinuse.

• Neverwashtheproductbyspreadingorpouringwater

onto it! There is the risk of electric shock!

• Nevertouchtheplugwithwethands!Neverunplugby

pullingonthecable,alwayspulloutbygrabbingtheplug.

• Usedetergents,softenersandsupplementssuitablefor

automatic washing machines only.

• Followtheinstructionsonthetextiletagsandonthe

detergent package.

• Theproductmustbeunpluggedduringinstallation,

maintenance,cleaningandrepairingprocedures.

• Alwayshavetheinstallationandrepairingprocedures

carriedoutbytheAuthorized Service Agent.

Manufacturershallnotbeheldliablefordamagesthat

mayarisefromprocedurescarriedoutbyunauthorized

persons.

• Ifthepowercableisdamaged,itmustbereplacedbythe

manufacturer,aftersalesserviceorasimilarlyqualified

person(preferablyanelectrician)orsomeonedesignated

bytheimporterinordertoavoidpossiblerisks.

1.2 Intended use

• Thisproducthasbeendesignedfordomesticuse.Itisnot

suitableforcommercialuseanditmustnotbeusedout

of its intended use.

• Theproductmustonlybeusedforwashingandrinsingof

laundry that are marked accordingly.

• Themanufacturerwaivesanyresponsibilityarisenfrom

incorrect usage or transportation.

1.3 Children's safety

• Packagingmaterialsaredangeroustochildren.Keep

packaging materials in a safe place away from reach of

the children.

• Electricalproductsaredangerousforthechildren.Keep

childrenawayfromtheproductwhenitisinuse.Donot

letthemtotamperwiththeproduct.Usechildlockto

prevent children from intervening with the product.

• Donotforgettoclosetheloadingdoorwhenleavingthe

room where the product is located.

• Storealldetergentsandadditivesinasafeplaceaway

fromthereachofthechildrenbyclosingthecoverofthe

detergent container or sealing the detergent package.

1.4 Package information

• Packagingmaterialsoftheproductaremanufactured

fromrecyclablematerialsinaccordancewithour

NationalEnvironmentRegulations.Donotdisposeofthe

packaging materials together with the domestic or other

wastes. Take them to the packaging material collection

pointsdesignatedbythelocalauthorities.

1.5 Disposing of the waste product

• Thisproducthasbeenmanufacturedwithhighquality

partsandmaterialswhichcanbereusedandaresuitable

forrecycling.Therefore,donotdisposetheproductwith

normal domestic waste at the end of its service life. Take

it to a collection point for the recycling of electrical and

electronicequipment.Pleaseconsultyourlocalauthorities

to learn the nearest collection point. Help protect the

environmentandnaturalresourcesbyrecyclingused

products.Forchildren'ssafety,cutthepowercableand

breakthelockingmechanismoftheloadingdoorsothat

itwillbenon-functionalbeforedisposingoftheproduct.

1.6 Compliance with WEEE Directive

This appliance’s packaging material is

recyclable.Helprecycleitandprotectthe

environmentbydroppingitoffinthemunicipal

receptacles provided for this purpose. Your

appliance also contains a great amount of

recyclablematerial.Itismarkedwiththislabel

to indicate the used appliances that should not

bemixedwithotherwaste.Thisway,theappliancerecycling

organisedbyyourmanufacturerwillbedoneunderthebest

possibleconditions,incompliancewithEuropeanDirective

2002/96/EConWasteElectricalandElectronicEquipment.

Contactyourtownhalloryourretailerfortheusedappliance

collectionpointsclosesttoyourhome.Wethankyoudoing

your part to protect the environment.

3 / EN

Washing Machine / User’s Manual

2 Installation

RefertothenearestAuthorisedServiceAgentforinstallation

oftheproduct.Tomaketheproductreadyforuse,review

the information in the user manual and make sure that the

electricity,tapwatersupplyandwaterdrainagesystemsare

appropriatebeforecallingtheAuthorizedServiceAgent.If

theyarenot,callaqualifiedtechnicianandplumbertohave

any necessary arrangements carried out.

Preparationofthelocationandelectrical,tapwaterand

waste water installations at the place of installation is

undercustomer'sresponsibility.

warning: Installationandelectricalconnectionsof

theproductmustbecarriedoutbytheAuthorized

ServiceAgent.Manufacturershallnotbeheldliablefor

damagesthatmayarisefromprocedurescarriedoutby

unauthorized persons.

warning: Priortoinstallation,visuallycheckiftheproduct

hasanydefectsonit.Ifso,donothaveitinstalled.

Damagedproductscauserisksforyoursafety.

Make sure that the water inlet and discharge hoses

aswellasthepowercablearenotfolded,pinchedor

crushed while pushing the product into its place after

installation or cleaning procedures.

2.1 Appropriate installation location

• Placethemachineonarigidfloor.Donotplaceitona

long pile rug or similar surfaces.

• Totalweightofthewashingmachineandthedryer-with

full load- when they are placed on top of each other

reachestoapprox.180kilograms.Placetheproduct

on a solid and flat floor that has sufficient load carrying

capacity!

• Donotplacetheproductonthepowercable.

• Donotinstalltheproductatplaceswheretemperature

mayfallbelow0ºC.

• Placetheproductatleast1cmawayfromtheedgesof

other furniture.

2.2 Removing packaging reinforcement

Tiltthemachinebackwardstoremovethepackaging

reinforcement.Removethepackagingreinforcementby

pullingtheribbon.

2.3 Removing the transportation locks

warning: Donotremovethetransportationlocksbefore

taking out the packaging reinforcement.

warning: Removethetransportationsafetyboltsbefore

operatingthewashingmachine!Otherwise,theproduct

willbedamaged.

1.Loosenalltheboltswithasuitablespanneruntilthey

rotate freely (C).

2.Removetransportationsafetyboltsbyturningthem

gently.

3.AttachtheplasticcoverssuppliedintheUserManualbag

into the holes on the rear panel. (P)

Keepthetransportationsafetyboltsinasafeplaceto

reusewhenthewashingmachineneedstobemoved

again in the future.

Never move the product without the transportation safety

boltsproperlyfixedinplace!

2.4 Connecting water supply

Thewatersupplypressurerequiredtoruntheproductis

between1to10bars(0.1–1MPa).Itisnecessaryto

have10–80litersofwaterflowingfromthefullyopen

tap in one minute to have your machine run smoothly.

Attachapressurereducingvalveifwaterpressureis

higher.

Ifyouaregoingtousethedoublewater-inletproduct

as a single (cold)water-inletunit,youmustinstallthe

suppliedstoppertothehotwatervalvebeforeoperating

theproduct.(Appliesfortheproductssuppliedwitha

blindstoppergroup.)

warning: Modelswithasinglewaterinletshouldnotbe

connectedtothehotwatertap.Insuchacasethelaundry

will get damaged or the product will switch to protection

mode and will not operate.

warning: Donotuseoldorusedwaterinlethosesonthe

newproduct.Itmaycausestainsonyourlaundry.

1.Connectthespecialhosessuppliedwiththeproductto

the water inlets on the product. Red hose (left) (max. 90

ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is

for cold water inlet.

warning: Ensure that the cold and hot water connections

are made correctly when installing the product.

Otherwise,yourlaundrywillcomeouthotattheendof

the washing process and wear out.

2.Tightenallhosenutsbyhand.Neveruseatoolwhen

tightening the nuts.

3. Open the taps completely after making the hose

connection to check for water leaks at the connection

Produktspecifikationer

Varumärke:	Smeg
Kategori:	tvättmaskin
Modell:	SWE106D-1
Inbyggd display:	Nej
Bredd:	600 mm
Djup:	480 mm
Höjd:	840 mm
Energieffektivitetsklass (gammal):	A+
Ljudnivå (tvätt):	56 dB
Maximal centrifugeringshastighet:	1000 RPM
Cykeltid (max):	160 min
Antal tvättprogram:	15
Doseringsassistent:	Ja
AquaStop-funktion:	Ja
Tvättprogram:	Hygiene/anti-allergy, Black, Hand, Wool, Jeans/denim, Sport
Minsta centrifugeringshastighet:	600 RPM
Dörrdiameter:	300 mm
Nominell kapacitet:	6 kg
Vattenkapacitet:	Kall
Invändigt material:	Polypropylen
Produktens färg:	Vit
Kontrolltyp:	Buttons, Rotary
Årlig vattenförbrukning tvätt:	8800 l
AC-inspänning:	220 - 240 V
Tvättklass:	C
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 - 60 hz
Redo för anpassad panel:	Nej
Gångjärnssida:	Vänster
Laddning:	Frontmatad
Dörr färg:	Vit
Fördröjd start timer:	Ja
Centrifugering klass:	C
Ljudnivå (spinn):	74 dB
Fördröjd start:	9 h
Justerbar centrifugeringshastighet:	Ja
Cykeltid (snabb-programmet):	130 min
Vattenförbrukning per omgång:	- l
Energiförbrukning vid tvätt:	1.014 kWh
Barnsäkert:	Ja
Lastbalansering systemet:	Ja
Skumkontrollssystem:	Ja
Restfukt:	62 %
Årlig energiförbrukning tvätt:	194 kWh
Material, trumma:	Rostfritt stål
Halv-belastning:	Ja
Dörröppningsvinkel:	180 °
