Sida 1/2
©2018 Sonance. All rights reserved. Sonance is a registered trademark of Dana Innovations. Due to continuous product improvement, all features
and specications are subject to change without notice. For the latest Sonance product specication information visit our website: www.sonance.com
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA(949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (949) 492-7777 04.26.18
i8 | i10 | i12 QUICKSTART GUIDE
IMPACT SUBWOOFER SERIES
33-8017
INSTALLATION
Audio Connections
Your Sonance Impact Subwoofer has exible connections that
let you use it in a wide variety of audio system congurations.
Line Level Input
You can connect the subwoofer’s line level input to a surround
processor or receiver’s line-level dedicated subwoofer LFE
output or a stereo preamp/integrated amplier’s left and right
variable main outputs. If your receiver has a subwoofer output
jack, you can connect your subwoofer, using the LEFT/LFE
input (see Figure 1).
Speaker Level Input
The subwoofer’s speaker inputs can be connected to the speaker
outputs of a receiver or integrated amp that does not have left and
right line-level outputs or a dedicated subwoofer output (see Figure 1).
Wireless Input
Connect line level inputs from the Wireless Transmitter to
the surround processor or receiver following the line level
instructions above. Once your Sonance Wireless Transmitter
and Impact Subwoofer are powered on, press and hold the
PAIR button on the back of the Wireless Transmitter. Once
the transmitter is in PAIR mode, the LED light will blink blue.
Release the PAIR button and within 30 seconds, press and
hold the Wireless PAIR button on the back of the subwoofer
until the light on front of the Wireless Transmitter turns solid
blue, then release. Your Impact Subwoofer and Wireless
Transmitter are now paired (see Figure 1).
Input Select
The subwoofer’s speaker inputs can be selected using the
INPUT SELECT toggle (see Figure 1).
Ground Lift
Your Sonance Impact Subwoofer features a ground lift switch
available to eliminate most grounding issues. To reduce the
ground current & induced noises, switch the GROUND LIFT from
ISOLATED to GROUNDED. Safety is not aected (see Figure 2).
Power Connection
Your Sonance Impact Subwoofer features a removable IEC
power cord (see Figure 3). (A power cord is included only with
115V versions of the subwoofers.) Plug the female end of the
power cord into the power cord connector on the subwoofer’s
rear panel and plug the male end into a grounded wall socket.
Do NOT plug the subwoofer’s power cord into a convenience
outlet on any other audio or video component.
SonARC for Subwoofers
Every Sonance cabinet subwoofer comes equiped with
SonARC built in. SonARC for subwoofers is an app driven
room correction software that allows you to tune your
subwoofer perfectly for the environment in which it is placed.
You can download the free app from the Apple App Store.
For more information visit www.sonance.com/sonarc.
For further detailed instructions please refer to manual online at:
www.sonance.com/impact/subwoofers
Box Contents
(1) Quickstart Guide
(1) Sonance Impact Subwoofer (i8, i10 or i12)
(1) IEC Power Cord
NOTE: WHEN USING THE SUBWOOFER’S SPEAKER INPUTS WE
RECOMMEND THE FOLLOWING MINIMUM SPEAKER WIRE SIZES:
• 16 GUAGE FOR A TOTAL WIRE LENGTH OF UP TO 500’
• 14 GUAGE FOR A TOTAL WIRE LENGTH OF UP TO 1,000’
NOTE: WHEN USING THIRD PARTY ROOM CORRECTION SOFTWARE,
BE SURE TO PERFORM THE SONANCE AUTOMATIC ROOM CORRECTION
APP (SonARC) ADJUSTMENTS FIRST.
IMPORTANT: NO SIGNAL WILL BE PASSED IF THE INPUT SELECT
BUTTON IS NOT PROPERLY SELECTED.
IMPORTANT: DO NOT PLUG THE POWER CORD INTO THE WALL OUTLET
UNTIL ALL SYSTEM CONNECTIONS HAVE BEEN MADE AND VERIFIED.
NOTE: IF YOU NEED TO USE AN EXTENSION CORD, USE ONLY A
HEAVY-DUTY (14-GAUGE OR LARGER) EXTENSION CORD TO AVOID
STARVING THE SUBWOOFER OF ALL THE CURRENT NECESSARY FOR
FULL-POWER OPERATION.
Figure 3: Power Cord Connector and Fuse Holder
Figure 1: Audio Connections
Figure 2: Ground Lift
