©2023 SONNEMAN - A Way of Light
Assembly Instructions
Chimes
Product Information
and Warnings
2043
Triple Sconce
IMPORTANT
Always disconnect the power before installing or replacing
Luminaires and before cleaning or other maintenance.
Consult a qualied, licensed electrician to ensure correct branch
circuit conductor.
Consulter un électricien qualié pour vous assurer que les
conducteurs de la dérivation sont adéquats.
Please read all included assembly instructions and warnings carefully
before installation. Contact Customer Service if you have any
questions or concerns. Before installation, please confirm that the
fixture is compatible with your supply voltage and dimming system,
if present.
LEDs are highly sensitive electronic devices, and must be treated
with care. Do not open any factory sealed compartments, and avoid
touching the LEDs with your hands or any object.
Although all our fixtures are equipped with protective devices,
LED electronic systems are vulnerable to power surges and supply
variations. Do not install LED fixtures on the same circuit as any
motors, appliances, or HVAC systems.
Do not remove or bypass any LED Driver or Transformer that is
provided with the fixture, and do not replace or substitute with
another power supply.
Fixtures must be wired in parallel on independent leads; do not
"daisy chain" multiple fixtures together or wire them in series.
All factory-made splices and connections must remain intact. LED
circuits are carefully designed and built, and improper connections
may damage the fixture.
Any mounting hardware is provided for your convenience
and should be used with discretion. Always use the appropriate
hardware for the mounting surface.
Instructions D'Installation
Multiple U.S. and foreign patents pending.
Assembly Instructions
1. Shut o power to the outlet box (A).
2. Make appropriate electrical connections to the power
supply (B) using wire nuts:
a. Connect the power supply’s live wire to the live
supply wire.
b. Connect the power supply’s neutral wire to the
neutral supply wire.
c. Connect the xture’s ground wire (green or
uncoated) to the ground supply wire. If no ground
wire is present in the outlet box, connect ground
wire to the mounting plate (C) using the green
screw (included).
Care Instructions:
Use a clean, dry cloth when dusting.
To protect the nish, avoid any harsh
abrasives or chemicals.
Notes:
• This xture is dimmable with Electronic Low Voltage (Trailing-Edge)
type dimmers, Incandescent (Leading-Edge) type dimmers, and
0-10V type dimmers only.
• The outlet box must be at least 3” tall, 2” wide, and 1.5” deep to t
the LED driver.
(E)
(B)
(C)
(A)
(D)
(F)
3. Place the power supply and all wired connections
carefully into the outlet box (A). Attach the mounting
plate (C) to the outlet box with outlet box screws (D).
4. Fit the xture (E) over the mounting plate (C). Tighten
the set screws (F) at top and bottom to secure.
5. Restore power to the outlet box (C).
