Assembly Instructions
Modern Tiers
Product Information
and Warnings
3522, 3523, 3524
3525, 3526, 3527
12", 16", 20" Dome /
12", 16", 20" Flat
LED Pendant
IMPORTANT
Always disconnect the power before installing or replacing
Luminaires and before cleaning or other maintenance.
Consult a qualified, licensed electrician to ensure correct branch
circuit conductor.
Consulter un électricien qualifié pour vous assurer que les
conducteurs de la dérivation sont adéquats.
Please read all included assembly instructions and warnings carefully
before installation. Contact Customer Service if you have any
questions or concerns. Before installation, please confirm that the
fixture is compatible with your supply voltage and dimming system,
if present.
LEDs are highly sensitive electronic devices, and must be treated
with care. Do not open any factory sealed compartments, and avoid
touching the LEDs with your hands or any object.
Although all our fixtures are equipped with protective devices,
LED electronic systems are vulnerable to power surges and supply
variations. Do not install LED fixtures on the same circuit as any
motors, appliances, or HVAC systems.
Do not remove of bypass any LED Driver or Transformer that is
provided with the fixture, and do not replace or substitute with
another power supply.
Fixtures must be wired in parallel on independent leads; do not
"daisy chain" multiple fixtures together or wire them in series.
All factory-made splices and connections must remain intact. LED
circuits are carefully designed and built, and improper connections
may damage the fixture.
The ends of coaxial pendant cords have been precisely stripped
and split at the factory and must not be field cut. Excess cord or
cable should be neatly coiled and reserved in the fixture canopy.
Any mounting hardware is provided for your convenience
and should be used with discretion. Always use the appropriate
hardware for the mounting surface.
Instructions D'Installation
Multiple U.S. and foreign patents pending.
Assembly Instructions
1. Shut o power to the Outlet Box (A).
2. Determine the height at which the xture is to be hung.
Use the supplied screw driver (B) to loosen the cord set screw (C).
Adjust the power cord (D) to the desired length.
Tighten the set screw to set.
3. Make appropriate electrical connections using wire nuts:
a. Connect the Power Supply’s live wire to the live supply wire.
b. Connect the Power Supply’s neutral wire to the neutral supply wire.
c. Connect the Power Supply’s ground wire (green or uncoated)
to the ground supply wire.
4. Place the power supply and connections in the outlet box (A),
then attach the mounting plate (E) with outlet box screws (F).
5. Install the canopy (G) to mounting plate (E),
secure with mounting screws (H).
6. Fasten the hang-straight stem (I) onto the xture.
7. Attach the Large Ring Shade (J) to the outer side of the
Shade hanger (K), with the 3 pre-installed Shade Hooks (L).
8. Attach the Small Ring Shade (M) to the inner side of the
Shade hanger (K), with the 3 pre-installed Shade Hooks (N)
9. Restore power to the xture.
Care Instructions:
Use a clean, dry cloth when dusting.
To protect the nish, avoid any harsh
abrasives or chemicals.
Note:
This fixture is dimmable with ELV (Trailing-Edge),
Incandescent (Leading-Edge), and 0-10V type dimmers only.
(A)
(E)
(F)
(H)
(G)
(I)
(J)
(M)
(N)
(L)
(K)
3527
3525
3522
3526
3523 3524
(B)
(C)
(D)
