NRN (4 / 8 / 16 Channel)

User Manual

N4NRN

N8NRN

N16NRN

Version 1.0

Features and specifications are subject to change, please check www.specotech.com for firmware updates.

Notes& Contents
            NVR  User  Manual


Notes

  Please read this user manual carefully to ensure that you can use the device correctly and safely.
  There may be several technical or printing errors in this manual. The updates will be added into the new version of this manual. The contents
of this manual are subject to change without notice.
  This device should be operated only from the type of power source indicated on the marking label. The voltage of the power must be verified
before using the same. Kindly remove the cables from the power source if the device is not to be used for a long period of time.
  Do not install this device near any heat sources such as radiators, heat registers, stoves or other devices that produce heat.
  Do not install this device near water. Clean only with a dry cloth.
  Do not block any ventilation openings and ensure proper ventilation around the machine.
  Do not power off the device at normal recording condition.
  This machine is for indoor use only. Do not expose the machine in rain or moist environment. In case any solid or liquid get inside the
machine’s case, please turn off the device immediately and get it checked by a qualified technician.
  Do not try to repair the device by yourself without technical aid or approval.


Contents
