User Manual
Thank you for purchasing our product. Speco Technologies is constantly developing and
improving products. We reserve the right to modify product design and specifications
without notice and without incurring any obligation.
V /V5T1/ / 5B1 V5D1 V5B1M/V5D1M/V5T1M
Warnings
Speco Technologies is not responsible for any problems caused by improper operation or repair.
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not use the device beyond specified voltage range.
Do not place the camera in extremely hot, cold (the operating temperature shall be (-4˚F~122˚F), dusty or
damp locations, and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for operating environment.
If the product does not work properly, please contact the dealer or where the product was purchased.
Keep away from liquid while in use.
sensitivity, low noise and distortion and supports HD video transmission with the common coaxial cable,
ensuring the requirement of the HD monitoring in the traditional surveillance system.
This camera series is the latest technology and advanced circuit design, which features high definition and
Introduction
High Resolution
Adopt high performance sensor, providing high definition and clear image.
High Transmission Performance
Real time transmission with high speed and long distance- .
DNR
Reduce noise from brightness and color signal .
OSD
Access the camera settings which can be clearly displayed through the main menu.
White Balance
Adjust the color temperature according to the environment automatically.
ICR Auto Switch
The filter will filter infrared light during the daytime and change to normal at night to
ensure a high sensitivity and clear image .
AGC
Adjust the gain of amplifier, enabling the camera to output the standard video signal in different
lighting condition.
Wide Dynamic Range (WDR)
When there are both very bright and very dark areas simultaneously in the field of view, this function
will balance the brightness level and provide clear images.
Backlight Compensation BLC ( )
When the back of the captured object is too much bright, you can set BLC for the captured object to
make it clearer.
1
Cables
Power Cable
Video Output
Video Switch Cable
Video Switch: Four video output modes can be optional--AHD, TVI, CVI and CVBS
(a) remove the cover of the video switch cable; (b) hold and press the button in the video
switch cable for 5 seconds to switch the current video output.
2
Before you start, please make sure that the wall or ceiling is stron g enough to withstand thr ee times
the weight of the camera. Please install and use the camera in the dry environment.
Youd better install back the lens cover or lower dome less than 4 hours after removing it.
The mounting types of cameras are only for reference.
Installation
Mounting for V5B1/V5T1
1. Drill the screw holes and the cable hole on the wall according to the drill template.
V5B1M
48mm
48mm
4.5
V5B1
4.6
48mm
48mm
2. Route and connect the cables .
3. Secure the mounting base with camera to the wall with screws as shown below.
