Sida 1/7
User Manual
Thank you for purchasing our product. Speco Technologies is constantly developing and
improving products. We reserve the right to modify product design and specifications
without notice and without incurring any obligation.
VLB9/VLB7/VLT9
Warnings
■ If the product does not work properly, please contact the dealer or where the product was purchased.
Speco Technologies is not responsible for any problems caused by improper operation or repair.
■ Do not expose the unit to heavy stress, violent vibration or long-term exposure to water and humidity
during transportation, storage, and/or installation.
■ Do not install near sources of heat.
■ Only install the product in environments inside the specification operating temperature and humidity
range.
■ Do not install the camera near power lines, radar equipment or other electromagnetic radiation.
■ Do not block any ventilation openings if any.
■ Use all the weatherproofing hardware requirement to minimize weather intrusion.
This camera series is the latest technology and advanced circuit design, which features high definition and
sensitivity, low noise and distortion and supports HD video transmission with the common coaxial cable,
ensuring the requirement of the HD monitoring in the traditional surveillance system.
Introduction
● High Resolution
Adopt high performance sensor, providing high definition and clear image.
● High Transmission Performance
Real time transmission with high speed and long distance- .
● DNR
Reduce noise from brightness and color signal .
● OSD
Access the camera settings which can be clearly displayed through the main menu.
● White Balance
Adjust the color temperature according to the environment automatically.
● AGC
Adjust the gain of amplifier, enabling the camera to output the standard video signal in different
lighting condition.
● Backlight Compensation BLC ( )
When the back of the captured object is too much bright, you can set BLC for the captured object to
make it clearer.
1
2
Cables
Power Cable
Video Output
Video Switch Cable
Video Switch: Four video output modes can be optional--AHD, TVI, CVI and CVBS
(a) remove the cover of the video switch cable; (b) hold and press the button in the video
switch cable for 5 seconds to switch the current video output.
Before you start, please make sure that the wall or ceiling is stron g enough to withstand three times
the weight of the camera. Please install and use the camera in the dry environment.
You’d better install back the lens cover or lower dome less than 4 hours after removing it.
The mounting types of cameras are only for reference.
Installation
►Mounting for VLB9/VLB7
1. Drill the screw holes and the cable hole on the wall according to the drill template.
2. Route and connect the cables .
3. Secure the mounting base with camera to the wall with screws as shown below.
∅4.6
∅25.1
∅82.0
∅72.2
120°
120°
62.5mm
18.1mm
36.1mm
