Optional Accessory

Specications

Image Sensor ...................1/3” 960H CCD

Resolution.........................700 TV lines

Minimum Illumination ........0.01 lux, 0 lux with IR on

Effective Pixels .................976 (H) x 494 (V)

Number of IR LEDs ..........VLEDT1HG/VLEDT1HW: 36

VLEDT2HG/VLEDT2HW: 24

IR Range ..........................VLEDT1HG/VLEDT1HW:

Up to 98’ (depending on scene reection)

VLEDT2HG/VLEDT2HW:

Up to 65’ (depending on scene reection)

IR LED Wavelength ..........850nm

IR Status ...........................IR on: under 10 lux, by CDS auto control

Electronic Shutter .............Auto (1/60 sec. - 1/100,000 sec.)

S/N Ratio ..........................More than 52dB

Backlight Compensation .....Auto

White Balance ..................Auto

AGC ..................................Auto

Gamma .............................0.45 typ.

Scanning System..............2:1 interlace

Synchronization ................Internal

Video Signal Output ..........1.0Vp-p / 75 ohms

Operating Temperature .....14° F – 122° F

Storage Temperature ........-4° F – 140° F

Power Consumption .........Max. 80mA (IR off)

VLEDT1HG/VLEDT1HW: max. 400mA (IR on)

VLEDT2HG/VLEDT2HW: max. 300mA (IR on)

Power Supply ...................12VDC (power supply not included)

Dimensions .......................VLEDT1HG/VLEDT1HW: 4.25” (H) x 4.5” (Dia.)

VLEDT2HG/VLEDT2HW: 3.2” (H) x 3.6” (Dia.)

Weight ..............................VLEDT1HG/VLEDT1HW: 1.2 lbs.

VLEDT2HG/VLEDT2HW: 10.4 oz.

960H IR Indoor/Outdoor Turret Camera

VLEDT1HG 2.8-12mm auto iris varifocal lens, dark grey housing

VLEDT1HW 2.8-12mm auto iris varifocal lens, white housing

VLEDT2HG 3.6mm xed lens, dark grey housing

VLEDT2HW 3.6mm xed lens, white housing

Features

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without notice

and without incurring any obligation. Spec Rev. 8/25/14

800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com

PSW5

12VDC

Power Supply

4.5” (Dia.)

4.25” (H)

3.6” (Dia.)

3.2” (H)

VLEDT1HG/VLEDT1HWVLEDT2HG/VLEDT2HW

• 1/3” 960H CCD

• 0 lux with 36 IR LEDs built-in (VLEDT1HG/VLEDT1HW)

0 lux with 24 IR LEDs built-in (VLEDT2HG/VLEDT2HW)

• 98’ IR range (depending on scene reection) (VLEDT1HG/VLEDT1HW)

65’ IR range (depending on scene reection) (VLEDT2HG/VLEDT2HW)

• IP66 compliant

• 2 year warranty
