LED (Blue)

Illuminateswhensound

sourceplaybackisin

progress.

Installation and Use Guide

Checking the Supplied Accessories / Names and Functions

Checkthatallofthesuppliedaccessoriesarepresent.

MCS10

Installation

double-sided tape

This manual

How to Install

Note:

・Afterinstallationusingtheinstallationdouble-sidedtapethatwasprovidedwiththeproduct,theDIP

switchescannotbechanged.

・IfthisproductwasinstalledinternallyinsideamC-Print3,itwillnotbepossibletousetheprinterUSBport.

・WhenthisproductisinstalledonthemC-Print3,mountRearcoverofthemC-Print3beforeuse.

・IfthisproductwasconnectedaftertheprinterpowerwasturnedON,itmaynotoperatecorrectly.

Software support

DriversandUtilitiesareavailable.

Fordetails,checkthefollowingwebsite.

URL: https://www.star-m.jp/utility-app.html

Pleaseturno󱐯aprinterandpulloutthepowerplugfromtheACoutletandbesuretowaitfor

morethan30secondsbeforeyouconnect/removemC-Sound.

●

Connecttheproductcabletotheexternaldevicedriveconnectorontheprinter.

●

Usetheinstallationdouble-sidedtapethatwasincludedinthepackageandapplyitatsuitable

locations.

・Installing internally

Setting Example )

evice drive connector

over

・Installing externally

How to Use

●

Thesoundsourceandvolumeforplaybackaresetbyinstructionsandcommandsfromthe

applicationwhichisused.

●

TheDIPswitchesontherearofmC-Soundcanbeusedtosettheproductplaybacksoundsource

andvolume.

Note: Even when the sound source and volume are set with the DIP switches, instructions and

commands from the application which is used take priority over the DIP switch settings.

DIP Switch2

12Volume

OFFOFFMute

OFFONLow

ONOFFMedium

ONONHigh

DIP Switch1

１２３４Sound Source

OFFOFFOFFOFFSound1

OFFOFFOFFONSound2

OFFOFFONOFFSound3

OFFOFFONONSound4

OFFONOFFOFFSound5

OFFONOFFONSound6

OFFONONOFFSound7

OFFONONONSound8

ONOFFOFFOFFSound9

ONOFFOFFONSound10

ONOFFONOFFSound11

ONOFFONONSound12

ONONOFFOFFSound13

ONONOFFONSound14

ONONONOFFSound15

ONONONONSound16

ONONDIP

123412

ONONDIP

123412

ON

OFF

ON

OFF

DIP Switch1DIP Switch2

＜Back of mC-Sound＞

Safety Information

・Donotuseinlocationswhereitwillbesplatteredwithliquidsuchaswater/oil,orwherethereareexcess

debrisanddust.

・Ifanythingirregularoccurs,immediatelyunplugtheprinterfromtheACoutlet.

EMI Class A Warning

https://download.starmicronics.com/manual/CE_DoC/ClassA_Warning.pdf

EU Declaration of Conformity

https://download.starmicronics.com/manual/CE_DoC/MCS10_CE_DoC_Newest.pdf

Italia: l’uso pubblico e soggetto ad autorizzazione generale da parte del rispettivo provider di servizi.

Noorwegen: Gebruik van radioapparatuur is niet toegestaan in het geograsche gebied binnen een straal van 20 km vanaf het centrum

van Ny-Ålesund, Svalbard.

This statement will be applied only for the printers marketed in Europe.

UK Declaration of Conformity

https://download.starmicronics.com/manual/CE_DoC/MCS10_UK_DoC_Newest.pdf

FCC/IC Statement

https://download.starmicronics.com/manual/FCC/FCC_IC_Statement_Type1.pdf

Mexico Statement

LA OPERACIÓN DE ESTE DISPOSITIVO ESTA SUJETA A LAS SIGUIENTES CONDICIONES:

a) Es posible que este equipo o dispositivo no cause interferencia perjudicial.

b) Este equipo o dispositivo debe aceptar cualquier tipo de interferencia, incluyendo la que pueda causar su operación no deseada.

Star Micronics Co.,Ltd. 20-10 Nakayoshida, Suruga-ku, Shizuoka-shi, Shizuoka 422-8654 Japan

UKREPStar Micronics Europe Ltd.Star House, Peregrine Business Park, Gomm Road, High Wycombe, Bucks. HP13 7DL, U.K.

ECREPAR ExpertsP.O.Box 5047 3620 AA Breukelen The Netherlands
