Sida 1/3

For the owners of other companies’ trademarks mentioned in this document,see Trademarks in our website (https://www.star-m.jp/eng/trademarks.html).



Connect the printer to the internet.

(See “Wired LAN” in Step 1 “Connect a cable”)



Scan the QR code from a smartphone or

tablet to access the registration site for

“Star Micronics Cloud Services”.



Follow the procedures to register the

printer with “Star Micronics Cloud

Services” to start using the services.

Registration

site

Digital Journal,

Printed

Promotion,

and more！

Service site

FREE services are available if you register

TSP100IV with Star Micronics Cloud Services.

Cloud Services

Star Windows Software



The Windows driver is included in the

Star Windows Software.

The Star Windows Software can be

used to configure the printer settings

and perform an operation test.



Download [ Star Windows Software ].



Extract the downloaded software and

execute “Setup.exe”.



Follow the wizard instructions and

complete software installation.

When using Windows

Star Quick Setup Utility



For a wired LAN connection, use the

tablet that is connected to the same

network as the TSP100IV.



Once a static IP address is assigned, IP address changes through the DHCP server will

not occur, so the specied connection destination device can be used continuously

once set.



Install [ Star Quick Setup Utility ].



Open the conguration utility, and

select [ Start Guide (Initial Settings)] - [

Search Printer].



Follow the instructions of the utility to

connect and set up a tablet.

When using Android/iOS

Preparing/setting up the conguration app

Conguration app

download site



Driver download site for Mac / Linux environment. (www.star-m.jp/tsp100iv-driver-wsw.html)

Use the configuration app to set up the

printer from a tablet or PC.

Scan the QR code on the right side or search

the app to access the download site.

Turn on the power to the printer



, and

check the blue LED lights up



Connect the included power cable to the

inlet on the back side of the

printer



Connect the plug of the power cable to the

outlet



Turn ON the Main

Unit

Power

Pull the end of the paper out straight



and push down both sides of the printer

cover to close



Insert a paper roll in the direction shown in

the illustration



To change the paper width, the

memory switch must be set. Refer to

the online manual for details.



When using a paper roll with 58 mm

width, install the supplied paper

guide into the printer.

Push the cover opening lever



and then

open the rear cover



Inserting a Paper Roll



When using a USB cable that is available commercially or that came with a smartphone or tablet, perform thorough operation verification.

Connect the LAN cable to the LAN connector of the printer



Connect the other side of the LAN cable to the hub/router



You will need:

LAN cable included with the printer

Wired LAN

Plug for the tablet / PC

(Type-A)

USB Type-C

» Windows / Mac / Linux

Connect the USB cable to the USB-C port (Windows) of the printer



Connect the other plug to the tablet or PC



Plug for the printer

(Type-C)

You will need:

USB cable included with the printer

Connect the USB cable to the USB-A port (Android 1.5A) of the printer



Connect the other plug to the smartphone or tablet



USB Type-A

» Android

You will need:

USB cable included with the printer

Plug for the printer

(Type-A)

Plug for the tablet

(Type-C)

Connect a cable

Easy Setup

Guide

Safety

Instructions

Rubber

Feet

Paper Roll

GuideUSB CablePower Cable* LAN CableTSP143IV-UE

This Sheet

If contents are missing or damaged, please contact the reseller that sold you the printer.

*accessories vary depending on the region where the printer was purchased.

What's Included

FAQ

TSP100IV online manual

This document explains the setup procedure for the

TSP100IV. For further instructions, please refer to the

TSP100IV online manual. Please read the instructions

before using the printer. You can also see FAQ from the

QR code on the inside of the printer.

Introduction

Easy Setup Guide

TSP100IV

80878780



Please refer to the above Service site for

available countries.

Produktspecifikationer

Varumärke:	Star Micronics
Kategori:	Skrivare
Modell:	TSP143IVUE
Vikt:	1300 g
Bredd:	140 mm
Djup:	169 mm
Höjd:	123 mm
Wi-Fi:	Nej
Maximal upplösning:	203 x 203 DPI
Certifiering:	UL, C-UL, TuV, FCC, VCCI, EN55022, CE
Internminne:	- MB
Modell:	POS-skrivare
Flashminne:	0.512 MB
Maximal rulldiameter:	83 mm
Skrivhastighet:	250 mm/sek
Skrivhuvudets livslängd:	100 km
Produktens färg:	Grå
Temperatur vid drift:	5 - 45 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	10 - 90 %
Kryptering/säkerhet:	WHQL
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	USB
USB-port:	Ja
Linux operativsystem som stöds:	Ja
Mac-kompatibel:	Ja
Utskriftsteknologi:	direkt termal
Medelströmförbrukning vid utskrift:	43 W
Max utskriftsupplösning, bredd:	80 mm
Stöds pappersbredd:	58 - 80 mm
Automatisk sax hållbarhet:	2 miljoner skär
Inbyggd sensor:	Lid opening sensor\nPaper exit sensor
Mediats tjocklek:	0.049 - 0.085 um
